Module No. 2248/2276/2278

2248/2276/2278-1

GENERAL GUIDE

•

Press

C

to change from mode to mode.

•

Pressing

L

in any mode illuminates the display for about 3 seconds.

•

If you do not perform any operation for a few minutes while a setting screen (with flashing digits) is on the display, the watch automatically exits the setting screen.

•

If you do not perform any operation for a few minutes in the Data Bank Mode or Day Counter Mode, the watch automatically reverts to the normal timekeeping screen.

The operational procedures for Modules 2248, 2276 and 2278 are identical. All of the illustrations in this manual show Module 2248.

Timekeeping Mode

Data Bank Mode

Press

C

.

Day Counter Mode

Alarm Mode

Stopwatch Mode

Dual Time Mode

[Module 2248]

[Module 2278]

[Module 2276]

TIMEKEEPING MODE

•

Press

D

to toggle between 12-hour and 24-hour

timekeeping.

•

With 12-hour timekeeping, times between noon and
midnight are indicated by P (pm), while no indicator
appears for times between midnight and noon.

•

No indicators do not appears for any time while 24-hour
timekeeping is selected.

To set the time and date

1. While in the Timekeeping Mode, hold down

A

until the

seconds digits flash on the display, indicating the
setting screen.

2. Press

C

to move the flashing in the sequence shown below.

DST

Seconds

Day

Hour

Year

Month

Minutes

3. While the seconds setting is selected (flashing), press

D

to reset it to 00. If you

press

D

while the seconds setting is in the range of 30 to 59, the seconds are

reset to 00 and 1 is added to the minutes. If the seconds setting is in the range of
00 to 29, the minutes count is unchanged.

•

While the DST

∗

setting is selected (DST on indicator is flashing), press

D

to

toggle it on (on) and off (OF). If DST setting is on, the DST on indicator is shown
in the Timekeeping Mode, Day Counter Mode and Alarm Mode.

4. While any other setting is selected (flashing), press

D

to increase it or

B

to

decrease it. Holding down either button changes the setting at high speed.

5. After you make the settings you want, press

A

to exit the setting screen.

•

The day of the week is automatically set in accordance with the date.

•

The date can be set within the range of January 1, 2000 to December 31, 2039.

•

The watch’s built-in full automatic calendar automatically makes allowances for
different month lengths and leap years. Once you set the date, there should be no
reason to change it except after the replacement of the watch’s battery.

∗

Daylight Saving Time (DST), which is also sometimes called “summer time”
advances the time for one hour, as is the custom in some areas during the
summer. Remember that not all countries or even local areas use Daylight Saving
Time.

ABOUT THE BACKLIGHT

Press

L

to illuminate the display for about 3 seconds.

•

The backlight of this watch employs an electro-luminescent (EL) light, which loses
its illuminating power after very long term use.

•

Frequent use of the backlight shortens the battery life.

•

The watch emits an audible sound whenever the display is illuminated. This does
not indicate malfunction of the watch.

•

The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.

•

The backlight automatically turns off whenever an alarm sounds.

Seconds

Day of
week

PM
indicator

Hour

Minutes

Month — Day

DST on indicator

Year

DATA BANK MODE

The Data Bank Mode lets you store up to 25 records,
each with a name (up to eight characters) and a phone
number (up to 12 digits). Data is automatically stored into
alphabetical order based on the name data. You can
recall records by scrolling through them on the display.

•

The record on the display when you exit the Data Bank
Mode appears first the next time you enter the Data
Bank Mode.

To input a new Data Bank record

1. In the Data Bank Mode, use

D

or

B

until the new data

screen appears.

•

If the new data screen does not appear when you
press

D

and

B

, it means that memory is full. To

store another record, you will first have to delete a
record stored in memory.

2. Hold down

A

and a cursor appears on the text area.

3. Use

D

or

B

to scroll through characters at the current cursor position. Characters

scroll in the sequence shown below.

A to Z

0 to 9

(Space)

Press .

Press .

•

Holding down either button scrolls at high speed.

4. When the character you want is at the current cursor position, press

C

to move the

cursor to the right.

5. Repeat the steps 3 and 4 to input the rest of the characters.

•

You can input up to eight characters for the name, though only three characters
are visible at a time. If the name you input has fewer than eight characters, use

C

to move the cursor to the eighth space (which means you would press

C

three times after inputting a five-character name).

•

Holding down

C

to move the cursor at high speed.

6. After you input the name, use

C

to move the cursor to the number area.

•

Pressing

C

while the cursor is located at the eighth character of the text area

advances to the number area. Pressing

C

while the cursor is located at the 12th

digit of the number area returns to the text area.

7. Use

D

or

B

to scroll through characters (hyphen, numbers, space) at the current

cursor position on the number area. Characters scroll in the sequence shown
below.

0 to 9

(Space)

Press .

Press .

•

Holding down either button scrolls characters at high speed.

•

You can input up to 12 digits for the number.

8. After inputting the name and number of the record, press

A

to store it and exit the

setting screen.

•

The display can show only three name characters at a time. Longer names scrolls
continuously from right to left. The symbol “ ” indicates that the character to the
left is the last, and the character to the right is the first.

To recall Data Bank data

In the Data Bank Mode, press

D

to scroll forward through the stored data items or

B

to scroll in reverse.

•

Holding down either button scrolls at high speed.

To edit Data Bank data items

1. In the Data Bank Mode, use

D

or

B

to display the data you want to edit.

2. Hold down

A

until the cursor appears in the display.

3. Use

C

to move the cursor to the character you want to change.

•

Holding down

C

to move the cursor at high speed.

4. Use

D

or

B

to change the character.

•

Holding down either button scrolls characters at high speed.

•

See step 3 of “To input a new Data Bank record” for information on inputting
name characters, and step 7 for inputting number characters.

5. After making the changes that you want, press

A

to store them and exit the setting

screen.

To delete a Data Bank record

1. In the Data Bank Mode, use

D

or

B

to display the record you want to delete.

2. Hold down

A

until the cursor appears in the display.

3. Press

D

and

B

at the same time. The message “CLR” appears in the display,

indicating that the record was deleted.

•

After the record is deleted, the cursor appears in the text area, ready for input.

4. Input a new record or press

A

to exit the setting screen.

Mode indicator

Text area

Remaining memory

Number area

[ New Data Screen ]

Operation Guide 5611

E-9

To do this: Enter this mode: See:

Use the stopwatch to measure elapsed time Stopwatch Mode E-26

Use the countdown timer Countdown Timer Mode E-30

Set an alarm time Alarm Mode E-33

E-8

Mode Reference Guide

The mode you should select depends on what you want to do.

To do this: Enter this mode: See:

x View the current date in the Home City

x Configure Home City and daylight saving time (DST)

settings

x Configure time and date settings

x View the World Time city and time

x Change the display illumination duration setting

x Enable/disable the button operation tone

Timekeeping Mode E-15

View the current time in one of 48 cities (31 time

zones) around the globe

World Time Mode E-23

E-7E-6

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-43

Main Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-45

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-46

Operating Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-49

User Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-60

E-5

Using the Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33

To enter the Alarm Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-33

To set an alarm time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-34

To test the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-35

To turn an alarm and the Hourly Time Signal on and off . . . . . . . . . . . . . . . . . E-36

To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-36

Illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-37

To turn on illumination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-37

To change the illumination duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-38

Adjusting Hand Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-39

Button Operation Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-41

To turn the button operation tone on and off . . . . . . . . . . . . . . . . . . . . . . . . . E-42

E-4

Checking the Current Time in a Different Time Zone . . . . . . . . . . . . . . . . . . . E-23

To enter the World Time Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-24

To view the time in another time zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-24

To specify standard time or daylight saving time (DST) for a city . . . . . . . . . . . E-25

Using the Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-26

To enter the Stopwatch Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-26

To perform an elapsed time operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-27

To pause at a split time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-27

To measure two finishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-27

Countdown Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-30

To enter the Countdown Timer Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-30

To configure the countdown timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-31

To perform a countdown timer operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-32

To stop the alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-32

E-3

Contents

About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

Things to check before using the watch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-2

Mode Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-8

Timekeeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-15

Configuring Home City Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-16

To configure Home City settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-16

To change the Daylight Saving Time (summer time) setting . . . . . . . . . . . . . . E-18

Adjusting the Digital Time and Date Settings . . . . . . . . . . . . . . . . . . . . . . . . . E-19

To configure the digital time and date settings . . . . . . . . . . . . . . . . . . . . . . . . E-19

E-2

Things to check before using the watch

1. Check the Home City and the daylight saving time (DST) setting.

Use the procedure under “To configure Home City settings” (page E-16) to configure

your Home City and daylight saving time settings.

Important!

x Proper World Time Mode data depends on correct Home City, time, and date

settings in the Timekeeping Mode. Make sure you configure these settings

correctly.

2. Set the current time.

x See “Adjusting the Digital Time and Date Settings” (page E-19).

The watch is now ready for use.

E-1

About This Manual

x Depending on the model of your watch, display text

appears either as dark figures on a light background, or

light figures on a dark background. All sample displays

in this manual are shown using dark figures on a light

background.

x Button operations are indicated using the letters shown

in the illustration.

x Note that the product illustrations in this manual are

intended for reference only, and so the actual product

may appear somewhat different than depicted by an

illustration.

E

ENGLISH

Congratulations upon your selection of this CASIO watch.

To ensure that this watch provides you with the years of service for which it is

designed, carefully read and follow the instructions in this manual, especially the

information under “Operating Precautions” and “User Maintenance”.

MA1906-EB

2019 CASIO COMPUTER CO., LTD.

Нашли ошибку в тексте? Выделите ее и нажмите Ctrl+Enter
