Foreword

GUID-8BD8A3A8-B294-458F-BC7B-E5197FB6203C

Welcome to the growing family of new NISSAN
owners. This vehicle is delivered to you with
confidence. It was produced using the latest
techniques and strict quality control.

This manual was prepared to help you under­stand the operation and maintenance of your
vehicle so that you may enjoy many miles of
driving pleasure. Please read through this
manual before operating your vehicle.

A separate Warranty Information Booklet
explains details about the warranties cov­ering your vehicle. The NISSAN Service
and Maintenance Guide explains details
about maintaining and servicing your ve­hicle. Additionally, a separate Customer
Care/Lemon Law Booklet (U.S. only) will
explain how to resolve any concerns you
may have with your vehicle, as well as
clarify your rights under your state’s lemon
law.

In addition to factory installed options, your
vehicle may also be equipped with additional
accessories installed by NISSAN or by your
NISSAN dealer prior to delivery. It is important
that you familiarize yourself with all disclosures,
warnings, cautions and instructions concerning
proper use of such accessories prior to operat­ing the vehicle and/or accessory. See a NISSAN
dealer for details concerning the particular

accessories with which your vehicle is
equipped.

Your NISSAN dealer knows your vehicle best.
When you require any service or have any
questions, we will be glad to assist you with the
extensive resources available to us.

READ FIRST — THEN DRIVE SAFELY

Before driving your vehicle, read your Owner’s
Manual carefully. This will ensure familiarity with
controls and maintenance requirements, assist­ing you in the safe operation of your vehicle.

GUID-593C27AD-1D70-42A2-A596-16F117E6B870

WARNING

IMPORTANT SAFETY INFORMATION
REMINDERS FOR SAFETY!

Follow these important driving rules to
help ensure a safe and comfortable trip
for you and your passengers!

. NEVER drive under the influence of

alcohol or drugs.

. ALWAYS observe posted speed lim-

its and never drive too fast for
conditions.

. ALWAYS give your full attention to

driving and avoid using vehicle
features or taking other actions that

could distract you.

. ALWAYS use your seat belts and

appropriate child restraint systems.
Pre-teen children should be seated
in the rear seat.

. ALWAYS provide information about

the proper use of vehicle safety
features to all occupants of the
vehicle.

. ALWAYS review this Owner’s Man-

ual for important safety information.

On-pavement and off-road driv­ing

This vehicle will handle and maneuver
differently from an ordinary passenger
car because it has a higher center of
gravity. As with other vehicles with fea­tures of this type, failure to operate this
vehicle correctly may result in loss of
control or an accident. Be sure to read
“Avoiding collision and rollover” and
“Driving safety precautions” in the “5.
Starting and driving” section of this
manual.

Картинка с сайта: manualmachine.com

MODIFICATION OF YOUR VEHI­CLE

This vehicle should not be modified.
Modification could affect its performance,
safety or durability, and may even violate
governmental regulations. In addition,
damage or performance problems result­ing from modification may not be covered
under NISSAN warranties.

WHEN READING THE MANUAL

This manual includes information for all
options available on this model. Therefore,
you may find some information that does
not apply to your vehicle.

All information, specifications and illustrations in
this manual are those in effect at the time of
printing. NISSAN reserves the right to change
specifications or design at any time without
notice.

GUID-95FC8501-974E-42A5-9BF3-8D0DF8D34DB7

IMPORTANT INFORMATION ABOUT
THIS MANUAL

You will see various symbols in this manual. They
are used in the following ways:

GUID-CC41887D-89CD-4B21-B9F2-EBE20E28E403

WARNING

This is used to indicate the presence of
a hazard that could cause death or
serious personal injury. To avoid or
reduce the risk, the procedures must
be followed precisely.

CAUTION

This is used to indicate the presence of
a hazard that could cause minor or
moderate personal injury or damage to
your vehicle. To avoid or reduce the risk,
the procedures must be followed care­fully.

SIC0697

If you see the symbol above, it means “Do not
do this” or “Do not let this happen”.

NOS1274

If you see a symbol similar to those above in an
illustration, it means the arrow points to the front
of the vehicle.

NOS1275

Arrows in an illustration that are similar to those
above indicate movement or action.

NOS1276

Arrows in an illustration that are similar to those

Картинка с сайта: manualmachine.com

above call attention to an item in the illustration.

CALIFORNIA PROPOSITION 65
WARNING

GUID-A176B850-BEC6-448D-95ED-3CE2548EED0F

WARNING

Engine exhaust, some of its constitu­ents, and certain vehicle components
contain or emit chemicals known to the
State of California to cause cancer and
birth defects or other reproductive
harm. In addition, certain fluids con­tained in vehicles and certain products
of component wear contain or emit
chemicals known to the State of Cali­fornia to cause cancer and birth defects
or other reproductive harm.

CALIFORNIA PERCHLORATE ADVI­SORY

Some vehicle parts, such as lithium bat­teries, may contain perchlorate material.
The following advisory is provided: “Per­chlorate Material — special handling may
apply, see www.dtsc.ca.gov/
hazardouswaste/perchlorate.”

GUID-F5F34C01-F9A4-4179-B302-7D5AC3FD83E7

Bluetooth®is a trademark owned
by Bluetooth SIG, Inc., and
licensed to Visteon Corporation.

SiriusXM Satellite Radio requires
subscription, sold separately.
Not available in Alaska, Hawaii or
Guam. For more information, visit
www.siriusxm.com.

C

*

2012 NISSAN MOTOR CO., LTD.

All rights reserved. No part of this Owner’s
Manual may be reproduced or stored in a
retrieval system, or transmitted in any form, or
by any means, electronic, mechanical, photo­copying, recording or otherwise, without the
prior written permission of Nissan Motor Co.,
Ltd.

Картинка с сайта: manualmachine.com

NISSAN CUSTOMER CARE
PROGRAM

NISSAN CARES …

Both NISSAN and your NISSAN dealer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your NISSAN dealer are
our primary concerns. Your NISSAN dealer is always available to assist you with all your automobile sales and service needs.

However, if there is something that your
NISSAN dealer cannot assist you with or you
would like to provide NISSAN directly with
comments or questions, please contact the
NISSAN Consumer Affairs Department using
our toll-free number:

For U.S. customers

1-800-NISSAN-1
(1-800-647-7261)

For Canadian customers

1-800-387-0122

GUID-7CE31796-E727-47BB-857D-7DEE3D3D183C

The Consumer Affairs Department will ask for
the following information:

. Your name, address, and telephone number
. Vehicle identification number (attached to

the top of the instrument panel on the
driver’s side)

. Date of purchase
. Current odometer reading
. Your NISSAN dealer’s name
. Your comments or questions

OR

You can write to NISSAN with the information at:

For U.S. customers

Nissan North America, Inc.
Consumer Affairs Department
P.O. Box 685003
Franklin, TN 37068-5003
or via e-mail at:
nnaconsumeraffairs@nissan-usa.com

For Canadian customers

Nissan Canada Inc.
5290 Orbitor Drive
Mississauga, Ontario L4W 4Z5
or via e-mail at:
information.centre@nissancanada.
com

If you prefer, visit us at:

www.nissanusa.com (for U.S. customers) or
www.nissan.ca (for Canadian customers)

We appreciate your interest in NISSAN and
thank you for buying a quality NISSAN vehicle.

Картинка с сайта: manualmachine.com

Table of

Illustrated table of contents

0

Contents

Safety — Seats, seat belts and supplemental
restraint system

Instruments and controls

Pre-driving checks and adjustments

Heater, air conditioner, audio and phone systems

Starting and driving

In case of emergency

Appearance and care

Maintenance and do-it-yourself

Technical and consumer information

1

2

3

4

5

6

7

8

9

Index

10

Картинка с сайта: manualmachine.com

0 Illustrated table of contents

Seats, seat belts and Supplemental Restraint

System (SRS) ……………………………………………………………………. 0-2

Exterior front ………………………………………………………………………. 0-3

Exterior rear ……………………………………………………………………….. 0-4

Passenger compartment …………………………………………………… 0-5

Cockpit ………………………………………………………………………………. 0-6

Instrument panel ……………………………………………………………….. 0-7

Meters and gauges …………………………………………………………… 0-8

Engine compartment ………………………………………………………… 0-9

MR16DDT engine ………………………………………………………. 0-9

Warning and indicator lights …………………………………………. 0-10

Картинка с сайта: manualmachine.com

SEATS, SEAT BELTS AND
SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)

1. Rear head restraints (Page 1-4)

2. Child restraint anchor points (for top tether strap
child restraint) (P.1-31)

3. Front head restraints (P.1-4)
— Front-seat Active Head Restraints (P.1-8)

4. Roof-mounted curtain side-impact supplemental
air bags (P.1-35)

GUID-52AF6180-E2C9-4318-AF4E-9DE2FF882623

10. Front seat-mounted side-impact supplemental
air bags (P.1-35)

11. Seat belt with pretensioners (P.1-47)

12. Occupant classification sensors (weight sen­sors)

— Advanced Air Bag System (P.1-41)

13. Front passenger air bag status light (P.1-43)

SSI0765

5. Seat belts (P.1-9)

6. Front seats (P.1-3)

7. Supplemental front-impact air bags (P.1-35)

8. LATCH (Lower Anchors and Tethers for CHil­dren) system (P.1-19)

9. Rear seats (P.1-4)
— Child restraints (P.1-17)

0-2 Illustrated table of contents

Картинка с сайта: manualmachine.com

EXTERIOR FRONT

GUID-CFE71A9F-8404-4B1C-84DD-FF8048FB8B69

1. Hood (P.3-20)

2. Windshield wiper and washer
— Switch operation (P.2-32)
— Blade replacement (P.8-17)
— Window washer fluid (P.8-12)

3. Parking lights, turn signal lights and front side
marker lights

7. Outside mirrors (P.3-25)

8. License plate installation (P.9-11)

9. Recovery hook (P.6-14)

10. Fog lights*
— Switch operation (P.2-38)
— Bulb replacement (P.8-28)

11. Headlights
— Switch operation (P.2-35)
— Bulb replacement (P.8-28)

12. Tires
— Wheels and tires (P.8-30, P.9-7)
— Flat tire (P.6-3)
— Tire Pressure Monitoring System (TPMS)

(P.2-15, P.5-4)

13. Doors
— Keys (P.3-2)
— Door locks (P.3-4)
— Remote keyless entry system* (P.3-7)
— Intelligent Key system* (P.3-11)
— Security system (P.2-29)

*: if so equipped

SSI0766

— Switch operation (P.2-35)
— Bulb replacement (P.8-27)

4. Moonroof* (P.2-47)

5. Side turn signal lights
— Switch operation (P.2-38)
— Bulb replacement (P.8-28)

6. Power windows (P.2-45)

Illustrated table of contents 0-3

Картинка с сайта: manualmachine.com

EXTERIOR REAR

GUID-CB027B35-0C4A-475A-B68D-3A7DA1020D00

1. Lift gate (P.3-21)
— Intelligent Key system* (P.3-11)

2. Rear window wiper and washer
— Switch operation (P.2-33)
— Window washer fluid (P.8-12)

3. High-mounted stop light (P.8-26)

4. Antenna (P.4-48)

0-4 Illustrated table of contents

— Bulb replacement (P.8-28)

9. Child safety rear door lock (P.3-7)
*: if so equipped

SSI0767

— Satellite radio antenna* (P.4-20)

5. Rear window defroster (P.2-34)

6. Fuel-filler door
— Operation (P.3-21)
— Fuel recommendation (P.9-3)

7. Rearview camera* (P.4-8)

8. Rear combination lights

Картинка с сайта: manualmachine.com

PASSENGER COMPARTMENT

GUID-7405A9C6-9DB6-43D6-BB85-7D8784BD39F1

1. Cargo area
— Cargo cover* (P.2-44)
— Cargo light (P.2-50, P.8-26)

2. Coat hook (P.2-43)

3. Sun visors (P.3-24)

4. Microphone (P.4-49)

5. Moonroof switch* (P.2-47)

JVC0184X

6. Room light and map lights (P.2-49)

7. Inside rearview mirror (P.3-25)

8. Door armrest
— Power window switch (P.2-45)
— Power door lock switch (P.3-6)

*: if so equipped

Illustrated table of contents 0-5

Картинка с сайта: manualmachine.com

COCKPIT

GUID-B18D921D-58BF-4EF2-ABA7-71D7C369DE14

1. Outside mirror remote control switch (P.3-25)

2. Headlight, fog light and turn signal switch
— Headlight (P.2-35)
— Turn signal light (P.2-38)
— Fog light* (P.2-38)

3. Steering wheel
— Electric power steering system (P.5-37)

0-6 Illustrated table of contents

— Horn (P.2-38)
— Driver’s supplemental air bag (P.1-35)

4. Wiper and washer switch (P.2-32)

5. Selector lever or shift lever
— Continuously Variable Transmission (CVT)

(P.5-17)
— Manual Transmission (MT) (P.5-22)

SSI0769

6. Fuse box cover (P.8-21)

7. Vehicle Dynamic Control (VDC) OFF switch
(P.5-40)

8. All-Wheel Drive (AWD) switch* (P.5-32)

9. Tilting steering wheel lever (P.3-24)

10. Steering-wheel-mounted controls (left side)
— Audio control (P.4-47)
— Bluetooth

®

Hands-Free Phone System con-

trol (P.4-49)

11. Ignition switch (models without Intelligent Key
system) (P.5-10)

12. Steering-wheel-mounted controls (right side)
— Cruise control switches (P.5-29)

13. Heated seat switch* (P.2-39)

*: if so equipped

Картинка с сайта: manualmachine.com

INSTRUMENT PANEL

GUID-E541DB03-EC76-48F2-8AC1-CDA28F389925

1. Meters and gauges (P.2-5)

2. Center ventilator (P.4-12)

3. Audio system* or Navigation system** (P.4-20)
— Clock* (P.2-40)

4. Hazard warning flasher switch (P.6-2)

5. Integrated Control System* (P. 2-21)
— Clock (P.2-23)

7. Side ventilator (P.4-12)

8. Fuel-filler door release handle (P.3-21)

9. Hood release handle (P.3-20)

10. Push-button ignition switch (models with Intel­ligent Key system) (P.5-12)

11. AUX/USB connector* (P.4-24)

12. Parking brake (P.5-28)

13. Cup holder (P.2-42)

14. Power outlet (P.2-41)

15. Glove box (P.2-43)

*: if so equipped
**: Refer to the separate Navigation System Own-

er’s Manual.

SSI0770

— Drive mode (P.5-24)
— Heater and air conditioner control (P.4-13)
— Defroster switch (P.2-34)

5. Heater and air conditioner control (models
without Integrated Control System) (P.4-13)

— Defroster switch (P.2-34)

6. Front passenger supplemental air bag (P.1-35)

Illustrated table of contents 0-7

Картинка с сайта: manualmachine.com

METERS AND GAUGES

GUID-ADD7704B-E089-476F-B602-46E63AF51822

1. Tachometer (P.2-8)

2. Engine coolant temperature gauge (P.2-8)

3. Vehicle information display (P.2-9)
— Odometer/twin trip odometer (P.2-6)
— Trip computer (P.2-10)
— Torque vectoring AWD (AWD model)

(P.2-11)

9. RESET switch for trip odometer (P.2-6)/Trip
computer mode switch (P.2-10)

*: if so equipped

SIC4601

— Outside air temperature (P.2-10)

4. Fuel gauge (P.2-9)

5. Speedometer (P.2-6)

6. Warning/indicator lights (P.2-12)

7. Instrument brightness control knob (P.2-37)

8. Continuously Variable Transmission (CVT) posi­tion indicator* (P.2-10)

0-8 Illustrated table of contents

Картинка с сайта: manualmachine.com

ENGINE COMPARTMENT

GUID-8EBBE60D-ED28-4099-9931-95512256E0F1

MR16DDT ENGINE

1. Engine oil filler cap (P.8-8)

2. Radiator filler cap (P.8-8)
— Vehicle overheat (P.6-10)

3. Brake and clutch* fluid reservoir (P.8-11)

4. Air cleaner (P.8-16)

5. Window washer fluid reservoir (P.8-12)

GUID-D335D9EC-1753-4C7F-815E-51D57D34351D

SDI2639

6. Engine drive belt location (P.8-15)

7. Engine oil dipstick (P.8-8)

8. Engine coolant reservoir (P.8-8)

9. Fuse/fusible link holder (P.8-19)

10. Battery (P.8-13)
— Jump starting (P.6-8)

*: for Manual Transmission (MT) models

Illustrated table of contents 0-9

Картинка с сайта: manualmachine.com

WARNING AND INDICATOR LIGHTS

GUID-56F49709-8C97-4624-BC9E-EFFB2D8B65F4

Warning

light

All-Wheel Drive (AWD) warning
light (yellow) (AWD model)

Anti-lock Braking System
(ABS) warning light

Brake warning light 2-13

Charge warning light 2-14

Door open warning light 2-14

Electric power steering warning
light

Engine oil pressure warning
light

Intelligent Key system warning
light*

Low fuel warning light 2-15

Low tire pressure warning light 2-15

Low washer fluid warning light* 2-16

P position selecting warning
light*

Seat belt warning light 2-16

Supplemental air bag warning
light

0-10 Illustrated table of contents

Name Page

2-13

2-13

2-14

2-14

2-14

2-16

2-17

Warning

light

Indicator

light

Name Page

Vehicle Dynamic Control (VDC)
warning light

Name Page

All-Wheel Drive (AWD) indica­tor light (green) (AWD model)

All-Wheel Drive (AWD)-V indi­cator light (green) (AWD model)

Continuously Variable Trans­mission (CVT) indicator light*

Cruise indicator light 2-18

Engine start operation indicator
light*

Exterior light indicator 2-18

Front passenger air bag status
light

High beam indicator light 2-18

Malfunction Indicator Light
(MIL)

Security indicator light 2-19

Turn signal/hazard indicator
lights

Vehicle Dynamic Control (VDC)
off indicator light

2-17

2-17

2-17

2-17

2-18

2-18

2-18

2-19

2-19

*: if so equipped

Картинка с сайта: manualmachine.com

1 Safety — Seats, seat belts and supplemental

restraint system

Seats ………………………………………………………………………………….. 1-2

Front seats ……………………………………………………………………. 1-3

Rear seats …………………………………………………………………….. 1-4

Head restraints …………………………………………………………….. 1-4

Seat belts …………………………………………………………………………… 1-9

Precautions on seat belt usage …………………………………… 1-9

Pregnant women ……………………………………………………….. 1-11

Injured persons ………………………………………………………….. 1-11

Three-point type seat belt …………………………………………. 1-11

Seat belt extenders ……………………………………………………. 1-14

Seat belt maintenance ………………………………………………. 1-14

Child safety ……………………………………………………………………… 1-15

Infants …………………………………………………………………………. 1-16

Small children …………………………………………………………….. 1-16

Larger children …………………………………………………………… 1-16

Child restraints ………………………………………………………………… 1-17

Precautions on child restraints …………………………………. 1-17

Lower Anchors and Tethers for CHildren

System (LATCH) ……………………………………………………….. 1-19

Rear-facing child restraint installation

using LATCH ……………………………………………………………… 1-21

Rear-facing child restraint installation using the

seat belts ………………………………………………………………….. 1-23

Forward-facing child restraint installation

using LATCH ……………………………………………………………. 1-26

Forward-facing child restraint installation using the

seat belts ………………………………………………………………….. 1-27

Installing top tether strap ………………………………………… 1-31

Booster seats …………………………………………………………… 1-31

Supplemental restraint system ………………………………………. 1-35

Precautions on supplemental restraint system ………. 1-35

NISSAN Advanced Air Bag System

(front seats) ……………………………………………………………… 1-41

Front seat-mounted side-impact supplemental
air bag and roof-mounted curtain side-impact

supplemental air bag systems ………………………………… 1-46

Seat belts with pretensioners (front seats) ……………. 1-47

Supplemental air bag warning labels …………………….. 1-49

Supplemental air bag warning light ……………………….. 1-49

Repair and replacement procedure ……………………….. 1-50

Картинка с сайта: manualmachine.com

SEATS

GUID-9968A6D7-C7DB-4923-8D40-B68E132879F1

. The seatback should not be reclined

any more than needed for comfort.
Seat belts are most effective when
the passenger sits well back and
straight up in the seat. If the seat­back is reclined, the risk of sliding
under the lap belt and being injured
is increased.

CAUTION

WARNING

. Do not ride in a moving vehicle

when the seatback is reclined. This
can be dangerous. The shoulder belt
will not be against your body. In an
accident, you could be thrown into it
and receive neck or other serious
injuries. You could also slide under
the lap belt and receive serious
internal injuries.

. For the most effective protection

when the vehicle is in motion, the
seat should be upright. Always sit

1-2 Safety — Seats, seat belts and supplemental restraint system

well back in the seat with both feet
on the floor and adjust the seat
properly. See “Precautions on seat
belt usage” (P.1-9).

. After adjustment, gently rock in the

seat to make sure it is securely
locked.

. Do not leave children unattended

inside the vehicle. They could un­knowingly activate switches or con­trols. Unattended children could
become involved in serious acci­dents.

SSS0133

When adjusting the seat positions, be
sure not to contact any moving parts to
avoid possible injuries and/or damage.

Картинка с сайта: manualmachine.com

SSS0792

SSS1129

FRONT SEATS
Front manual seat adjustment

Forward and backward:

Pull the lever

GUID-55B40E63-3184-4977-9580-6F5DF10262BF

GUID-5F8B59F4-CE83-4388-A330-B31F2E8A1C04

GUID-3448E018-0BC4-4D17-AD0E-3BB850F23C53

1

up and hold it while you slide

*

the seat forward or backward to the desired
position. Release the lever to lock the seat in
position.

Reclining:

To recline the seatback, pull the lever

GUID-3448E018-0BC4-4D17-AD0E-3BB850F23C53

*

2

up and
lean back. To bring the seatback forward, pull
the lever up and lean your body forward. Release
the lever to lock the seatback in position.

The reclining feature allows adjustment of the

seatback for occupants of different sizes for
added comfort and to help obtain proper seat
belt fit. (See “Precautions on seat belt usage”
(P.1-9).) Also, the seatback can be reclined to
allow occupants to rest when the vehicle is
stopped and the transmission is in the P (Park)
position or N (Neutral) position with the parking
brake fully applied.

Safety — Seats, seat belts and supplemental restraint system 1-3

Seat lifter (for driver’s seat):

GUID-3448E018-0BC4-4D17-AD0E-3BB850F23C53

Pull up or push down the adjusting lever to
adjust the seat height until the desired position
is achieved.

Картинка с сайта: manualmachine.com

CAUTION

When folding or returning the
seatback(s) to the upright position, to
avoid injury to yourself and others:

. Make sure that the seat path is clear

before moving the seat.

injury.

. When returning the seatbacks to the

upright position, be certain they are
completely secured in the latched
position. If they are not completely
secured, passengers may be injured
in an accident or sudden stop.

HEAD RESTRAINTS

GUID-8F6B0940-703A-44EA-9F15-263BA73C554F

SSS1142

REAR SEATS
Folding

Before folding the rear seats:

Secure the seat belts on the seat belt hooks on
the side wall. (See “Seat belt hooks” (P.1-14).)

To fold the seatback, pull the adjusting knob
To return the seatback to the seating position, lift

up each seatback and push it to the upright
position until it is latched.

1-4 Safety — Seats, seat belts and supplemental restraint system

GUID-2FD3862E-47A4-488D-87D0-EC77846BDDE4

GUID-93DCD3BA-E481-4D39-82ED-FEB595DFCE01

GUID-3448E018-0BC4-4D17-AD0E-3BB850F23C53

1

*

. Do not fold down the rear seats

when occupants are in the rear seat
area or any objects are on the rear
seats.

. Never allow anyone to ride in the

cargo area or on the rear seats
when they are in the fold-down

.

position. Use of these areas by
passengers without proper re­straints could result in serious injury
in an accident or sudden stop.

. Properly secure all cargo with ropes

or straps to help prevent it from
sliding or shifting. Do not place
cargo higher than the seatbacks. In
a sudden stop or collision, unse­cured cargo could cause personal

WARNING

WARNING

Head restraints supplement the other
vehicle safety systems. They may pro­vide additional protection against injury
in certain rear end collisions. Adjust the
head restraints properly, as specified in
this section. Check the adjustment after
someone else uses the seat. Do not
attach anything to the head restraint
stalks or remove the head restraint. Do
not use the seat if the head restraint
has been removed. If the head restraint
was removed, reinstall and properly
adjust the head restraint before an
occupant uses the seating position.
Failure to follow these instructions
can reduce the effectiveness of the
head restraints. This may increase the

Картинка с сайта: manualmachine.com

risk of serious injury or death in a
collision.

JVR0051X

The illustration shows the seating positions
equipped with head restraints. The head re­straints are adjustable. The front head restraints
have multiple adjustment notches. The rear head
restraints have one adjustment notch.

Indicates the seating position is equipped

with a head restraint.
+ Indicates the seating position is not equipped

with a head restraint or adjustable headrest.

Safety — Seats, seat belts and supplemental restraint system 1-5

Components.

GUID-DA49A6E4-F1AC-4350-AD51-CAB31A2EB702

1. Head restraint (front shown)

2. Adjustment notches

3. Lock knob

4. Stalks

SSS0992

Картинка с сайта: manualmachine.com

SSS0997

Adjustment

GUID-EB8890F9-0620-49ED-A2CF-1AABFBA6A9FA

Adjust the head restraint so the center is level
with the center of your ears.

To raise the head restraint, pull it up.

SSS0993

SSS0994

To lower, push and hold the lock knob and push
the head restraint down.

1-6 Safety — Seats, seat belts and supplemental restraint system

Картинка с сайта: manualmachine.com

ment notches. The rear head restraints have one
adjustment notch.

SSS0995

Removal

GUID-DF75CB90-1E53-47F8-83F0-888DDA65151F

Use the following procedure to remove the
adjustable head restraints.

1. Pull the head restraint up to the highest

position.

2. Push and hold the lock knob.

3. Remove the head restraint from the seat.

4. Store the head restraint properly in a secure

place so it is not loose in the vehicle.

5. Reinstall and properly adjust the head

restraint before an occupant uses the
seating position.

The front head restraints have multiple adjust-

SSS0996

Install

GUID-C3856631-8898-412D-B440-8420406175F0

1. Align the head restraint stalks with the holes
in the seat. Make sure that the head restraint
is facing the correct direction. The stalk with
the adjustment notches
stalled in the hole with the lock knob

1

must be in-

*

2

.

*

2. Push and hold the lock knob and push the
head restraint down.

3. Properly adjust the head restraint before an
occupant uses the seating position.

The front head restraints have multiple adjust­ment notches. The rear head restraints have one
adjustment notch.

Safety — Seats, seat belts and supplemental restraint system 1-7

Картинка с сайта: manualmachine.com

SSS0508

The front head restraints have multiple adjust­ment notches.

Properly adjust the Active Head Restraints as
described in this section.

Front-seat Active Head Restraints

GUID-387F51B4-7CEA-4F79-A0BF-23E93E24350D

The Active Head Restraint moves forward
utilizing the force that the seatback receives
from the occupant in a rear-end collision. The
movement of the head restraint helps support
the occupant’s head by reducing its backward
movement and helping absorb some of the
forces that may lead to whiplash-type injuries.

Active Head Restraints are effective for colli­sions at low to medium speeds in which it is said
that whiplash injury occurs most.

Active Head Restraints operate only in certain
rear-end collisions. After the collision, the head
restraints return to their original positions.

1-8 Safety — Seats, seat belts and supplemental restraint system

Картинка с сайта: manualmachine.com

SEAT BELTS

PRECAUTIONS ON SEAT BELT

GUID-92182A0D-FB70-4BA9-81E5-FB1DCE59F1D2

USAGE

If you are wearing your seat belt properly
adjusted, and you are sitting upright and well
back in your seat with both feet on the floor, your
chances of being injured or killed in an accident
and/or the severity of injury may be greatly
reduced. NISSAN strongly encourages you and
all of your passengers to buckle up every time
you drive, even if your seating position includes a
supplemental air bag.

Most U.S. states and Canadian provinces
or territories specify that seat belts be
worn at all times when a vehicle is being
driven.

GUID-E275423E-F1F3-4DC0-BFA1-B05D62DB881D

SSS0136

SSS0134

Safety — Seats, seat belts and supplemental restraint system 1-9

Картинка с сайта: manualmachine.com

SSS0016

SSS0014

WARNING

. Every person who drives or rides in

this vehicle should use a seat belt at
all times. Children should be prop­erly restrained in the rear seat and,
if appropriate, in a child restraint.

. The seat belt should be properly

adjusted to a snug fit. Failure to do
so may reduce the effectiveness of
the entire restraint system and in­crease the chance or severity of
injury in an accident. Serious injury
or death can occur if the seat belt is
not worn properly.

. Always route the shoulder belt over

your shoulder and across your
chest. Never put the belt behind
your back, under your arm or across
your neck. The belt should be away
from your face and neck, but not
falling off your shoulder.

. Position the lap belt as low and

snug as possible AROUND THE
HIPS, NOT THE WAIST. A lap belt
worn too high could increase the
risk of internal injuries in an acci­dent.

. Be sure the seat belt tongue is

securely fastened to the proper
buckle.

. Do not wear the seat belt inside out

or twisted. Doing so may reduce its
effectiveness.

. Do not allow more than one person

to use the same seat belt.

. Never carry more people in the

vehicle than there are seat belts.

. If the seat belt warning light glows

continuously while the ignition is
turned ON with all doors closed and
all seat belts fastened, it may in­dicate a malfunction in the system.
Have the system checked by a
NISSAN dealer.

. No changes should be made to the

seat belt system. For example, do
not modify the seat belt, add mate­rial, or install devices that may
change the seat belt routing or
tension. Doing so may affect the
operation of the seat belt system.
Modifying or tampering with the
seat belt system may result in
serious personal injury.

1-10 Safety — Seats, seat belts and supplemental restraint system

Картинка с сайта: manualmachine.com

. Once a seat belt pretensioner has

activated, it cannot be reused and
must be replaced together with the
retractor. See a NISSAN dealer.

. Removal and installation of the

pretensioner system components
should be done by a NISSAN dealer.

. All seat belt assemblies, including

retractors and attaching hardware,
should be inspected after any colli­sion by a NISSAN dealer. NISSAN
recommends that all seat belt as­semblies in use during a collision be
replaced unless the collision was
minor and the belts show no da­mage and continue to operate prop­erly. Seat belt assemblies not in use
during a collision should also be
inspected and replaced if either
damage or improper operation is
noted.

. All child restraints and attaching

hardware should be inspected after
any collision. Always follow the
restraint manufacturer’s inspection
instructions and replacement re­commendations. The child restraints
should be replaced if they are

damaged.

PREGNANT WOMEN

GUID-DE7C6527-7C0B-46D7-8BFB-6F6024B255C2

NISSAN recommends that pregnant women use
seat belts. The seat belt should be worn snug,
and always position the lap belt as low as
possible around the hips, not the waist. Place
the shoulder belt over your shoulder and across
your chest. Never put the lap/shoulder belt over
your abdominal area. Contact your doctor for
specific recommendations.

INJURED PERSONS

GUID-466EC31A-8F1E-42C5-9CEC-DA817E973D99

NISSAN recommends that injured persons use
seat belts, depending on the injury. Check with
your doctor for specific recommendations.

THREE-POINT TYPE SEAT BELT

GUID-944271FB-5AEB-40D3-8EEE-0CE619EC4E2F

WARNING

. Every person who drives or rides in

this vehicle should use a seat belt at
all times.

. Do not ride in a moving vehicle

when the seatback is reclined. This
can be dangerous. The shoulder belt
will not be against your body. In an
accident, you could be thrown into it
and receive neck or other serious

Safety — Seats, seat belts and supplemental restraint system 1-11

injuries. You could also slide under
the lap belt and receive serious
internal injuries.

. For the most effective protection

when the vehicle is in motion, the
seat should be upright. Always sit
well back in the seat with both feet
on the floor and adjust the seat belt
properly.

. Do not allow children to play with

the seat belts. Most seating posi­tions are equipped with Automatic
Locking Retractor (ALR) mode seat
belts. If the seat belt becomes
wrapped around a child’s neck with
the ALR mode activated, the child
can be seriously injured or killed if
the seat belt retracts and becomes
tight. This can occur even if the
vehicle is parked. Unbuckle the seat
belt to release the child. If the seat
belt can not be unbuckled or is
already unbuckled, release the child
by cutting the seat belt with a
suitable tool (such as a knife or
scissors) to release the seat belt.

Картинка с сайта: manualmachine.com

Fastening the seat belts

GUID-7A8EC8B3-4437-4D52-96D2-2DBE6487FB7F

1. Adjust the seat. (See “Seats” (P.1-2).)

2. Slowly pull the seat belt out of the retractor
and insert the tongue into the buckle until
you hear and feel the latch engage.

.

The retractor is designed to lock

during a sudden stop or on impact.
A slow pulling motion permits the
belt to move and allows you some
freedom of movement in the seat.

.

If the seat belt cannot be pulled from

its fully retracted position, firmly pull
the belt and release it. Then
smoothly pull the belt out of the
retractor.

1-12 Safety — Seats, seat belts and supplemental restraint system

SSS0292

SSS0290

3. Position the lap belt portion low and snug
on the hips as shown.

4. Pull the shoulder belt portion toward the
retractor to take up extra slack. Be sure the
shoulder belt is routed over your shoulder
and across your chest.

The front passenger seat and the rear seating
positions three-point seat belts have two modes
of operation:

. Emergency Locking Retractor (ELR)
. Automatic Locking Retractor (ALR)

The Emergency Locking Retractor (ELR) mode
allows the seat belt to extend and retract to
allow the driver and passengers some freedom

Прежде всего здесь мы найдем ответы касательно конструкции, возможностей устройства Nissan Juke (2013), использования отдельных аксессуаров и ряд информации, позволяющей вполне использовать все функции и упрощения.

После удачной покупки оборудования/устройства стоит посвятить несколько минут для ознакомления с каждой частью инструкции Nissan Juke (2013). Сейчас их старательно готовят или переводят, чтобы они были не только понятными для пользователя, но и чтобы выполняли свою основную информационно-поддерживающую функцию.
