Dishwasher

SR…

User manual

en

Register your product on My Siemens and discover
exclusive services and offers.

siemens-home.bsh-group.com/welcome

The future moving in.

Siemens Home Appliances

Картинка с сайта: manualmachine.com

en

Table of contents

Safety………………………………………..4

General information……………………..4

Intended use……………………………….4

Restriction on user group……………..4

Safe installation …………………………..5

Safe use …………………………………….6

Damaged appliance …………………….8

Risk to children …………………………..9

Safety systems ………………………….10

Preventing material damage ……..11

Safe installation …………………………11

Safe use …………………………………..11

Childproof lock1……………………….12

Electric childproof lock……………….12

Environmental protection and

saving energy…………………………..12

Disposing of packaging ……………..12

Saving energy……………………………12

AquaSensor1……………………………..13

Installation and connection……….13

Scope of supply ………………………..13

Installing and connecting the ap-

pliance ……………………………………..13

Drainage connection ………………….14

Drinking water connection ………….14

Electrical connection ………………….14

Familiarising yourself with

your appliance………………………….15

Appliance …………………………………15

Controls ……………………………………16

Programmes …………………………….18

Information for test institutes ……….20

Additional functions …………………20

Features…………………………………..21

Top basket ……………………………….22

Bottom basket …………………………..23

Cutlery basket …………………………..24

Cutlery drawer …………………………..24

Etagere …………………………………….25

Folding prongs ………………………….25

Small items holder …………………….26

Knife shelf…………………………………26

Baking sheet spray head ……………26

Basket heights…………………………..27

Before using for the first time ……28

Performing initial start-up ……………28

Water softening system…………….28

Overview of water hardness set-

tings…………………………………………28

Setting water softening system ……29

Special salt ……………………………….29

Switching off water softening

system ……………………………………..30

Regeneration of the water

softening system ……………………….30

Rinse aid system………………………31

Rinse aid ………………………………….31

Setting the amount of rinse aid……31

Switching rinse aid system off …….32

Detergent …………………………………32

Suitable detergents ……………………32

Unsuitable detergents ………………..33

Information on detergents …………..33

Adding detergent ………………………34

Tableware ………………………………..35

Damage to glass and tableware ….35

Arrange tableware ……………………..36

Removing tableware…………………..37

1

Depending on the appliance specifications

2

Картинка с сайта: manualmachine.com

en

Basic operation ………………………..37

Opening appliance door …………….37

Switching on the appliance …………37

Setting a programme …………………37

Setting additional functions …………37

Setting timer programming …………37

Starting the programme ……………..38

Interrupting programme ……………..38

Terminate programme………………..38

Switching off appliance ………………38

Basic settings…………………………..39

Overview of basic settings ………….39

Changing basic settings……………..41

Cleaning and servicing……………..41

Cleaning the tub ………………………..41

Self-cleaning interior1………………….41

Cleaning products ……………………..42

Tips on appliance care……………….42

Machine Care 1………………………42

Filter system ……………………………..43

Cleaning spray arms ………………….44

Troubleshooting……………………….45

Appliance safety………………………..45

Error code / Fault display / Sig-

nal……………………………………………47

Washing results…………………………49

Information on display panel……….55

Malfunctions ……………………………..56

Mechanical damage…………………..57

Noise ……………………………………….57

Clean wastewater pump……………..58

Customer Service……………………..59

Product number (E-Nr.) and pro-

duction number (FD) ………………….60

AQUA-STOP guarantee1……………..60

Technical specifications……………60

Transportation, storage and

disposal …………………………………..58

Removing the appliance …………….58

Protect appliance from frost………..59

Transporting the appliance …………59

Disposing of old appliance …………59

1

Depending on the appliance specifications

3

Картинка с сайта: manualmachine.com

en Safety

Safety

Please read the safety information to ensure that you use the ap­pliance safely.

General information

¡ Read this instruction manual carefully. Only this will ensure you

use the appliance safely and efficiently.

¡ Keep the instruction manual and the product information safe

for future reference or for the next owner.

¡ Check the appliance after unpacking it. Do not connect the ap-

pliance if it has been damaged in transit.

Intended use

Read the information on intended use to ensure that you use the
appliance correctly and safely.
Only use this appliance:

¡ For cleaning household tableware.
¡ In private households and in enclosed spaces in a domestic en-

vironment.

¡ Up to an altitude of max. 4000m above sea level.

Restriction on user group

Avoid risks to children and vulnerable persons.
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be performed by chil­dren unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.

4

Картинка с сайта: manualmachine.com

Safety en

Safe installation

Follow these safety instructions when installing the appliance.

WARNING‒Risk of injury!

Improper installation may cause injury.

▶

When installing and connecting the appliance, follow the in­structions in the manual and installation instructions.

WARNING‒Risk of electric shock!

¡ Improper installation is dangerous.

▶

Connect and operate the appliance only in accordance with
the specifications on the rating plate.

▶

Connect the appliance to a power supply with alternating
current only via a properly installed socket with earthing.

▶

The protective conductor system of the domestic electrical
installation must be properly installed.

▶

Never equip the appliance with an external switching
device, e.g. a timer or remote control.

▶

When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access is not
possible, an all-pole isolating switch must be installed in the
permanent electrical installation according to the installation
regulations.

▶

When installing the appliance, check that the power cable is
not trapped or damaged.

¡ Cutting through the supply hose or immersing the Aqua-Stop

valve in water is dangerous.

▶

Never immerse the plastic housing in water. The plastic
housing on the supply hose contains an electric valve.

▶

Never cut through the supply hose. The supply hose con­tains electric power cables.

WARNING‒Risk of fire!

It is dangerous to use an extended power cord and non-ap­proved adapters.

▶

Do not use extension cables or multiple socket strips.

▶

If the power cord is too short, contact Customer Service.

5

Картинка с сайта: manualmachine.com

en Safety

▶

Only use adapters approved by the manufacturer.

WARNING‒Risk of injury!

Hinges move when opening and closing the appliance door
and can cause injury.

▶

If built-under or integrable appliances are not in a cavity so
that one side is accessible, the hinge area must be covered
at the side. Covers are available from Customer Service or
specialist outlets.

WARNING‒Risk of tipping!

Improper installation may cause the appliance to tip up.

▶

Only install built-under or integrable appliances under a
continuous worktop that is securely connected to adjacent
cabinets.

WARNING‒Risk of burns!

If the appliance is not installed properly, this may result in
burns.

▶

With free-standing appliances, ensure that they are installed
with the back panel against a wall.

Safe use

WARNING‒Risk of serious harm to health!

Failure to comply with safety instructions and directions for
use on packagings of detergent and rinse aid products may
cause serious harm to health.

▶

Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.

WARNING‒Risk of explosion!

¡ Adding solvents to the interior of the appliance may cause ex-

plosions.

▶

Never add solvents to the interior of the appliance.

6

Картинка с сайта: manualmachine.com

Safety en

¡ Highly caustic alkaline or highly acidic cleaning agents in con-

junction with aluminium parts in the interior of the appliance
may cause explosions.

▶

Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, in
conjunction with aluminium parts (e.g. grease filters of ex­tractor hoods or aluminium pans), e.g. for the Machine Care
programme.

WARNING‒Risk of injury!

¡ Leaving the appliance door open may result in injury.

▶

Only open the appliance door to load or unload tableware
in order to prevent accidents, e.g. through tripping.

▶

Do not sit or stand on the appliance door when open.

¡ Knives and utensils with sharp points can cause injuries.

▶

Arrange knives and utensils with sharp points in the cutlery
basket with the points downwards, on the knife shelf or in
the cutlery drawer.

WARNING‒Risk of scalding!

If you open the appliance door while the programme is run­ning, hot water may splash out of the appliance.

▶

Open the appliance door carefully if the programme is still
running.

WARNING‒Risk of tipping!

Overfilling the Baskets may cause the appliance to tip up.

▶

Never overfill the Baskets with free-standing appliances.

WARNING‒Risk of electric shock!

¡ An ingress of moisture can cause an electric shock.

▶

Only use the appliance in enclosed spaces.

▶

Never expose the appliance to intense heat or humidity.

▶

Do not use steam- or high-pressure cleaners to clean the
appliance.

7

Картинка с сайта: manualmachine.com

en Safety

¡ If the insulation of the power cord is damaged, this is danger-

ous.

▶

Never let the power cord come into contact with hot appli­ance parts or heat sources.

▶

Never let the power cord come into contact with sharp
points or edges.

▶

Never kink, crush or modify the power cord.

Damaged appliance

Follow the safety instructions if the appliance is damaged.

WARNING‒Risk of electric shock!

¡ If the appliance or the power cord is damaged, this is danger-

ous.

▶

Never operate a damaged appliance.

▶

Never operate an appliance with a cracked or fractured sur­face.

▶

Never pull on the power cord to unplug the appliance. Al­ways unplug the appliance at the mains.

▶

If the appliance or the power cord is damaged, immediately
unplug the power cord or switch off the fuse in the fuse box
and turn off the water tap.

▶

«Call Customer Service.» →Page59

▶

Repairs to the appliance should only be carried out by
trained specialist staff.

¡ Incorrect repairs are dangerous.

▶

Repairs to the appliance should only be carried out by
trained specialist staff.

▶

Only use genuine spare parts when repairing the appliance.

▶

If the power cord of this appliance is damaged, it must be
replaced with a special connection cable, which is available
from the manufacturer or his Customer Service.

8

Картинка с сайта: manualmachine.com

Safety en

Risk to children

Follow the safety instructions if there are children in your home.

WARNING‒Risk of suffocation!

¡ Children may put packaging material over their heads or wrap

themselves up in it and suffocate.

▶

Keep packaging material away from children.

▶

Do not let children play with packaging material.

¡ Children may breathe in or swallow small parts, causing them

to suffocate.

▶

Keep small parts away from children.

▶

Do not let children play with small parts.

WARNING‒Risk of harm to health!

Children can lock themselves in the appliance, thereby putting
their lives at risk.

▶

With redundant appliances, unplug the power cord. Then
cut through the cord and damage the lock on the appliance
door beyond repair so that the appliance door will no longer
close.

WARNING‒Risk of crushing!

With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.

▶

Keep an eye on children when opening and closing the ap­pliance door.

WARNING‒Risk of chemical burns!

Rinse aid and detergent may cause chemical burns to the
mouth, throat and eyes.

▶

Keep children away from detergent and rinse aid products.

▶

Keep children away from the appliance when open. The wa­ter in the interior of the dishwasher is not drinking water. It
may contain residues of detergents and rinse aid.

9

Картинка с сайта: manualmachine.com

en Safety

WARNING‒Risk of injury!

Children may get their fingers caught in the slots of the tablet
collecting tray and injure themselves.

▶

Keep children away from the appliance when open.

WARNING‒Risk of suffocation!

Children may become trapped in the appliance and suffocate.

▶

Use the childproof lock if fitted.

▶

Never let children play with or operate the appliance.

Safety systems

Protect children from possible hazards resulting from the appli­ance.
Depending on the features of the model, the appliance comes
with a
→«Childproof lock», Page12.

10

Картинка с сайта: manualmachine.com

Preventing material damage en

Preventing material damage

Preventing material dam­age

Preventing material damage

Safe installation

Follow the instructions when installing
the appliance.

ATTENTION!

¡ Improper installation of the appli-

ance may cause damage.

▶

If the dishwasher is installed
above or below other domestic
appliances, follow the informa­tion on installation in combina­tion with a dishwasher in the in­stallation instructions for the in­dividual appliances.

▶

If there is no information or if the
installation instructions do not in­clude the relevant information,
contact the manufacturer of
these appliances to check that
the dishwasher can be installed
above or below these appli­ances.

▶

If no information is available
from the manufacturer, the dish­washer should not be installed
above or below such appli­ances.

▶

To ensure the safe operation of
all domestic appliances, con­tinue following the installation in­structions for the dishwasher.

▶

Do not install the dishwasher un­der a hob.

▶

Do not install the dishwasher
near heat sources, e.g. radiat­ors, heat storage tanks, ovens
or other appliances that gener­ate heat.

¡ Modified or damaged water hoses

may result in material damage and
damage to the appliance.

▶

Never kink, crush, modify or cut
through water hoses.

▶

Only use the water hoses sup­plied with the appliance or genu­ine spare hoses.

▶

Never re-use water hoses that
have been used before.

¡ If the water pressure is too high or

too low, this may impair function­ing of the appliance.

▶

Make sure that the water pres­sure in the water supply system
is min. 50kPa (0,5bar) and
max. 1000kPa (10bar).

▶

If the water pressure exceeds
the maximum value specified, a
pressure-reducing valve must be
installed between the drinking
water connection and the hose
set of the appliance.

Safe use

Follow the instructions when using
the appliance.

ATTENTION!

¡ Escaping water vapour can dam-

age fitted units.

▶

When the programme ends,
leave the appliance to cool
down for a while before opening
the door.

¡ Special salt can damage the tub

due to corrosion.

▶

To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the pro­gramme starts.

¡ Detergent may damage the water

softening system.

▶

Only fill the dispenser of the wa­ter softening system with special
dishwasher salt.

¡ Unsuitable cleaning agents may

damage the appliance.

▶

Do not use a steam cleaner.

11

Картинка с сайта: manualmachine.com

en Childproof lock

▶

So as not to scratch the finish
on the appliance, do not use
sponges with a rough surface or
abrasive cleaning agents.

▶

To prevent corrosion, do not use
sponge cloths on dishwashers
with a stainless steel front or
rinse such cloths thoroughly
several times before using them
for the first time.

Childproof lock

Childproof lock

Childproof lock

The childproof lock lets you protect

1

children from possible hazards result­ing from the appliance.
Depending on the features of the ap­pliance model, the appliance comes
with an electric childproof lock.

Electric childproof lock

The electric childproof lock makes it
more difficult to open the appliance
door.
You can activate or deactivate the
electric childproof lock in the «Basic
settings» →Page39.

WARNING

Risk of suffocation!

Children may become trapped in the
appliance and thus suffocate.

▶

Activate the electric childproof lock
and close the appliance door.

→«Opening appliance door»,

Page37

Environmental protection and saving energy

Environmental protection
and saving energy

Environmental protection and saving energy

Help protect the environment by us­ing your appliance in a way that con­serves resources and by disposing of
reusable materials properly.

Disposing of packaging

The packaging materials are environ­mentally compatible and can be re­cycled.

▶

Sort the individual components by
type and dispose of them separ­ately.

Information about current disposal
methods are available from your
specialist dealer or local authority.

Saving energy

If you follow these instructions, your
appliance will use less electricity and
less water.

Use the Eco 50° programme.

The Eco 50° programme is en­ergy efficient and environmentally
friendly.
→«Programmes», Page18

If you do not have much tableware to
wash, use the additional Half Load
function.

1

The programme will adjust to a
lower load and consumption will
be reduced.
→«Additional functions», Page20

1

Depending on the appliance specifications

12

Картинка с сайта: manualmachine.com

AquaSensor

1

The AquaSensor is an optical meas­uring device (light barrier) which
measures the turbidity of the washing
water. You can save water with the
AquaSensor.
Use of the AquaSensor depends on
the programme. If the soiling level is
low, the washing water is used in the
next wash cycle, so reducing water
consumption by 3-6 litres. If the soil­ing level is is greater, the washing
water is drained off and replaced with
fresh water. In the automatic pro­grammes the temperature and run­ning time are additionally adjusted to
the level of soiling.

Installation and connection

Installation and connec­tion

Installation and connection

Scope of supply

After unpacking all parts, check for
any damage in transit and complete­ness of the delivery.
If you have any complaints, contact
the dealer who sold you the appli­ance or our Customer Service.

Note:The appliance was tested at
the factory to check it is in working
order. It is possible that water has left
marks on the appliance. These
marks will disappear after the first
wash cycle.

The delivery consists of the following:

¡ Dishwasher
¡ Instruction manual
¡ Installation instructions
¡ Warranty
¡ Installation material
¡ Steam guard plate

1

1

Installation and connection en

¡ Rubber apron
¡ Mains cable
¡ Quick reference guide

1

1

Installing and connecting the
appliance

You can position your built-under or
integrable appliance in a fitted kit­chen between wooden and plastic
walls. If you subsequently install your
dishwasher as a free-standing appli­ance, you must stop it from tipping
over, e.g. by screwing it to the wall or
installing it under a continuous work­top that is securely connected to ad­jacent cabinets.

1. «Follow the safety instructions.»

→Page4

2. «Follow the instructions for elec-

trical connection.» →Page14

3. Check the «Scope of supply»

→Page13 and the condition of
the appliance.

4. Consult the installation instructions

for the installation dimensions re­quired.

5. Make the appliance level using the

height-adjustable feet.
Make sure that the appliance is

standing on the floor securely.

6. «Install the drainage connection.»

→Page14

7. «Install the drinking water connec-

tion.» →Page14

8. Connect the appliance to the

power supply.

1

Depending on the appliance specifications

13

Картинка с сайта: manualmachine.com

en Installation and connection

Drainage connection

Connect your appliance to drainage
connection so dirty water is dis­charged via the wash cycle.

Installing the drainage connection

1. Consult the installation instructions

supplied for the steps required
here.

2. Connect the wastewater hose to

the outlet connection of the siphon
using the enclosed parts.

3. When doing so, check that the

wastewater hose is not kinked,
crushed or twisted.

4. Also check that there is no cover

in the drainage system preventing
the wastewater from being dis­charged.

Drinking water connection

Connect your appliance to a drinking
water connection.

Installing the drinking water
connection

Note

¡ If you are replacing the appliance,

you must use a new water supply
hose.

1. Consult the installation instructions

supplied for the steps required
here.

2. Connect the appliance to the drink-

ing water connection using the en­closed parts.

Observe the «Technical data»
→Page60.

3. When doing so, check that the

drinking water connection is not
kinked, crushed or twisted.

Electrical connection

Connect your appliance to the power
supply.

Connecting the appliance to the
electricity supply

Notes

¡ Follow the «Safety instructions»

→Page5.

¡ Connect the appliance to alternat-

ing current only, in the range of
220 — 240V and 50Hz or 60Hz.

¡ Please note that the water safety

system is only functional if there is
a power supply.

1. Insert the non-heating appliance

plug of the power cable into the
appliance.

2. Insert the mains plug of the appli-

ance into a nearby socket.
The connection data for the appli-

ance can be found on the rating
plate.

3. Check that the mains plug is inser-

ted properly.

14

Картинка с сайта: manualmachine.com

Familiarising yourself with your appliance en

Familiarising yourself with your appliance

Familiarising yourself with your appliance

Familiarising yourself with your appliance

Appliance

You can find an overview of the parts of your appliance here.

Rating plate Rating plate with «E number and FD number»

1

Depending on the appliance specifications

→Page60.
The data you need for «Customer Service»

→Page59.

15

Картинка с сайта: manualmachine.com

en Familiarising yourself with your appliance

Detergent dispenser «Detergent» →Page32 is added to the detergent

dispenser.

Bottom basket «Bottom basket» →Page23

Filter system «Filter system» →Page43

Dispenser for special salt Add special salt for the «Water softening system»

→Page28 to the dispenser for special salt.

Tablet collecting tray During the wash cycle tablets automatically fall out of

the detergent dispenser into the tablet collecting tray
where they can fully dissolve.

Top basket «Top basket» →Page22

Cutlery drawer

EmotionLight

Etagere «Etagere» →Page25

Upper spray arms The upper spray arms wash the tableware in the top

Lower spray arm The lower spray arm washes the tableware in the bot-

Cutlery basket

1

1

1

«Cutlery drawer» →Page24

Interior lighting of the appliance.

→«Overview of basic settings», Page39

basket.
If the tableware has not been washed properly, clean
the spray arms.

→«Cleaning spray arms», Page44

tom basket.
If the tableware has not been washed properly, clean
the spray arms.

→«Cleaning spray arms», Page44

«Cutlery basket» →Page24

Dispenser for rinse aid Add rinse aid for the «Rinse aid system» →Page31

1

Depending on the appliance specifications

to the dispenser for rinse aid.

Controls

The controls are used to configure all functions of your appliance and to obtain
information about the operating status.
With some buttons you can perform different functions.

16

Картинка с сайта: manualmachine.com

Familiarising yourself with your appliance en

ON/OFF button «Switching on the appliance» →Page37

«Switching off the appliance» →Page38

Programme buttons «Programmes» →Page18

Water supply display «Display for water supply lights up» →Page48

Special salt refill indicator «Water softening system» →Page28

Rinse aid refill indicator «Rinse aid system» →Page31

Programme buttons and additional
functions

Start button and reset button «Starting the programme» →Page38

Timer programming «Setting timer programming» →Page37

Door opener

Display The display shows information about the remain-

1

Depending on the appliance specifications

1

«Programmes» →Page18
«Additional functions» →Page20

«Terminating the programme» →Page38

«Opening the appliance door» →Page37

ing running time or the basic settings. You can
change the basic settings via the display and the
setting buttons.

→«Changing basic settings», Page41

17

Картинка с сайта: manualmachine.com

en Programmes

Programmes

Programmes

Programmes

You can find an overview of the pro­grammes that can be selected here.
Different programmes, which can be
found on the control panel of your
appliance, are available depending
on the appliance configuration.
The running time may vary depend­ing on the programme selected. The
running time depends on the water
temperature, the quantity of dishes,
the level of soiling and the «Additional
function» →Page20 selected. The

running time will change if the rinse
aid system is switched off or rinse
aid needs to be added.
The consumption values can be
found in the quick reference guide.
The consumption values relate to
normal conditions and a water hard­ness of 16-20°E. Different influen­cing factors such as water temperat­ure or pipe pressure may result in
deviations.

Programme Use Programme se-

quence

Intensive 70°

Tableware:
¡ Washing pots and

pans, non-fragile
tableware and cut­lery.

Level of soiling:

Intensive:

¡ PreRinse
¡ Cleaning 70°C
¡ Intermediate rinse
¡ Rinsing 69°C
¡ Drying

¡ Removing stubborn

burned or dried-on
food remnants con­taining starch and
protein.

When using powder de­tergent, you can also
apply a little to the in­side of the appliance
door.

Auto 45-65°

Tableware:
¡ Cleaning mixed

tableware and cut­lery.

Level of soiling:

Sensor-controlled:
¡ Optimised by

sensors depending
on the soiling of the
washing water.

¡ Removing common

household food rem­nants lightly dried­on.

Additional functions

All

→«Additional func­tions», Page20

All

→«Additional func­tions», Page20

18

Картинка с сайта: manualmachine.com

Programmes en

Programme Use Programme se-

quence

Eco 50°

Silence 50

Tableware:
¡ Cleaning mixed

tableware and cut-

lery.
Level of soiling:
¡ Removing common

household food rem-

nants lightly dried-

on.

Tableware:
¡ Cleaning mixed

tableware and cut-

lery.
Level of soiling:
¡ Removing common

Most economical pro­gramme:

¡ Pre-Rinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Rinsing 60°C
¡ Drying
¡ Automatic opening

of appliance door

Reduced noise:

¡ PreRinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Rinsing 65°C
¡ Drying

household food rem-

nants lightly dried-

on.

Glass 40°

Tableware:
¡ Cleaning delicate

tableware, cutlery,

temperature-sensit-

ive plastics, glasses

and stemware in the

Particularly gentle:

¡ PreRinse
¡ Cleaning 40°C
¡ Intermediate rinse
¡ Rinsing 60°C
¡ Drying

stemware basket.
Level of soiling:
¡ Removing lightly ad-

hering fresh food

remnants.

Quick 65°

Tableware:
¡ Cleaning mixed

tableware and cut-

lery.
Level of soiling:

Time-optimised:

¡ Cleaning 65°C
¡ Intermediate rinse
¡ Rinsing 70°C
¡ Drying

¡ Removing common

household food rem-

nants lightly dried-

on.

Additional functions

All

→«Additional func­tions», Page20

IntensiveZone
Half Load
HygienePlus
ExtraDry
Shine & Dry

→«Additional func­tions», Page20

IntensiveZone
VarioSpeedPlus
Half Load
ExtraDry
Shine & Dry

→«Additional func­tions», Page20

ExtraDry
Shine & Dry

→«Additional func­tions», Page20

19

Картинка с сайта: manualmachine.com

en Additional functions

Programme Use Programme se-

quence

1 hr Programme

Tableware:
¡ Cleaning mixed

tableware and cut-

lery.
Level of soiling:

Time-optimised:

¡ Cleaning 65°C
¡ Intermediate rinse
¡ Rinsing 70°C
¡ Drying

¡ Removing common

household food rem-

nants lightly dried-

on.

Quick 45°

Tableware:
¡ Cleaning delicate

tableware, cutlery,

temperature-sensit-

Time-optimised:

¡ Cleaning 45°C
¡ Intermediate rinse
¡ Rinsing 55°C

ive plastics and

glasses.
Level of soiling:
¡ Removing lightly ad-

hering fresh food

remnants.
Tableware:

¡ Cleaning all types of

Cold rinse suitable:
¡ Pre-Rinse

tableware.

PreRinse

Level of soiling:
¡ Cold rinsing, inter-

mediate cleaning.

— Machine Care 70°C None

Machine Care

Additional functions

ExtraDry
Shine & Dry

→«Additional func­tions», Page20

ExtraDry
Shine & Dry

→«Additional func­tions», Page20

None

Information for test institutes

Test institutes are provided with in­formation for comparability tests, e.g.
according to EN60436.
These are the conditions for conduct­ing the tests, however they are not
the results or consumption values.
E-mail enquiries to: dishwasher@test­appliances.com
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rat­ing plate on the appliance door.

20

Additional functions

Additional functions

Additional functions

You can find an overview of the addi­tional functions that can be selected
here. Different additional functions,
which can be found on the control
panel of your appliance, are available
depending on the appliance configur­ation.

Additional func­tion

VarioSpeedPlus

Use

¡ The running time is

shortened by 20% to
66% depending on the
washing programme.

Картинка с сайта: manualmachine.com

Features en

Additional func­tion

Half Load

HygienePlus

IntensiveZone

Use

¡ Energy and water con-

sumption are increased.

¡ Switch on with small

loads.

¡ It is recommended

adding less detergent
to the detergent dis­penser than for a full
machine load.

¡ The running time is

shortened.

¡ Energy and water con-

sumption are reduced.

¡ To ensure a higher hy-

giene status for the ap­pliance and dishes, the
temperature is raised
and maintained for an
extra-long period.

¡ Especially suitable for

cleaning chopping
boards or baby bottles.

¡ Continuous use of this

function increases the
hygiene status.

¡ This will increase the

running time and en­ergy consumption.

¡ Switch on with mixed

loads containing table­ware with different soil­ing levels, e.g. place
very soiled pots and
pans in the bottom bas­ket and normally soiled
tableware in the top
basket.

¡ The spray pressure in

the bottom basket is in­creased and the max­imum programme tem­perature held longer.
This will increase the
running time and en­ergy consumption.

Additional func-

Use

tion

¡ For a better drying res-

ExtraDry

ult the final rinse tem­perature is increased
and the drying phase
extended.

¡ Especially suitable for

drying plastic parts.

¡ There is a slight in-

crease in energy con­sumption and the run­ning time is extended.

¡ To avoid marks and im-

Shine & Dry

prove drying, the quant­ity of water is increased
and the drying phase
extended.

¡ Energy consumption in-

creases.

¡ Use rinse aid.

Features

Features

Features

You can find an overview of the pos­sible features of your appliance and
how to use them here.
These features depend on the model
of your appliance.

21

Картинка с сайта: manualmachine.com

en Features

Top basket

Arrange cups and glasses in the top
basket.

Knife shelf
You can adjust the height of the top

basket to make room for larger items
of tableware.

Adjusting top basket with side
levers

To wash large items of tableware in
the baskets, adjust the shelf position
of the top basket.

1. Pull out the top basket.

2. To prevent the basket from sud-

denly dropping down, hold the
side of the basket by the top edge.

1

3. Press in the levers on the right and

left on the outside of the basket.

The basket can then slip down
slightly.

4. Raise or lower the basket evenly to

the right level.
→«Basket heights», Page27

Check that the basket is level on
both sides.

5. Slide the basket back in.

1

Depending on the appliance specifications

22

Adjusting top basket with pairs of
rollers

To wash large items of tableware in
the baskets, adjust the shelf position
of the top basket.

1. Pull out the top basket.

Картинка с сайта: manualmachine.com

Features en

2. Remove the basket.

3. Insert the basket at the right bas-

ket height.
→«Basket heights», Page27

Bottom basket

Arrange pans and plates in the bot­tom basket.

Cutlery basket
Large plates up to a diameter of

31/34cm1 can be arranged as
shown.

1

Check that the basket is level on
both sides.

4. Slide the basket back in.

1

Depending on the appliance specifications

23

Картинка с сайта: manualmachine.com

en Features

Cutlery basket

Arrange cutlery in the cutlery basket,
always without sorting it and with the
sharp points downwards.

Cutlery drawer

Arrange cutlery in the cutlery drawer.

1. To fold down a side shelf, push the

lever forwards and fold down
the side shelf ⁠.

2. To fold down the front prongs,

push the lever forwards and fold
down the prongs ⁠.

Tip

If you want to return the cutlery
drawer to the original position, fold
the side shelf back up until it clicks
into position.

Arrange cutlery with the points and
sharp edges downwards.
You can reorganise the cutlery
drawer to make more space for
longer/wider items of cutlery.

Reorganising cutlery drawer

1

1

You can fold down the side shelves
and front prongs to make more
space for longer/wider items of cut­lery.

1

Depending on the appliance specifications

24

Картинка с сайта: manualmachine.com

Features en

Etagere

Use the etagere and space under­neath for small cups and glasses or
for large items of cutlery, e.g.
wooden spoons or serving cutlery.

You can adjust the height of the
etagere.
If you do not need the etagere, you
can fold it up.

Adjusting etagere

You can adjust the height of the
etagere.

1. Position the etagere vertically and

1

1

pull it upwards ⁠.

Folding prongs

Use the folding prongs to position
tableware securely, e.g. plates.

You can fold the prongs down to po­sition pans, bowls and glasses

1

better.

Folding down prongs

If you do not need the prongs, fold
them down.

1. Push the lever forwards and fold

down the prongs ⁠.

1

2. Position the etagere at a slight

angle and move to the right height

⁠.

3. Push the etagere down.

a The etagere clicks into position.

1

Depending on the appliance specifications

2. To use the folding prongs again,

fold them back up.

a The folding prongs click in posi-

tion.

25

Картинка с сайта: manualmachine.com

en Features

Small items holder

Use the small items holder to posi­tion small items of tableware, e.g.
light plastic parts.

Knife shelf

Use the knife shelf for long, sharp ob­jects and long items of cutlery.

Baking sheet spray head

Use the baking sheet spray head to
clean large items of tableware, e.g.
trays, grilles and plates.

Arrange max. 2baking sheets and
2grilles as shown to ensure that the
spray jet can reach all parts.

Note:Check that the appliance is al­ways operated with the top basket or
the baking sheet spray head.

Inserting baking sheet spray head

Use the baking sheet spray head in­stead of the top basket to clean large
trays, grilles and plates.

1. Remove top basket.

2. Insert the baking sheet spray head

in the holder and turn to the
right ⁠.

26

a The baking sheet spray head

clicks into position.

Картинка с сайта: manualmachine.com

Features en

Removing baking sheet spray head

If you no longer require the baking
sheet spray head, remove it from the
appliance.

1. Turn the baking sheet spray head

anticlockwise and remove from the
holder.

2. Insert the top basket in the appli-

ance.

Basket heights

Set the baskets at the right height.

Appliance height 81.5cm with cutlery basket

Level Top basket Bottom basket

1 max. ø 22 cm 31 cm
2 max. ø 24.5 cm 27.5 cm
3 max. ø 27 cm 25 cm

Appliance height 81.5cm with cutlery drawer

Level Top basket Bottom basket

1 max. ø 16 cm 31 cm
2 max. ø 18.5 cm 27.5 cm
3 max. ø 21 cm 25 cm

Appliance height 86.5cm with cutlery basket

Level Top basket Bottom basket

1 max. ø 24 cm 34 cm
2 max. ø 26.5 cm 30.5 cm
3 max. ø 29 cm 28 cm

Appliance height 86.5cm with cutlery drawer

Level Top basket Bottom basket

1 max. ø 18 cm 34 cm
2 max. ø 20.5 cm 30.5 cm
3 max. ø 23 cm 28 cm

27

Картинка с сайта: manualmachine.com

en Before using for the first time

Before using for the first time

Before using for the
first time

Before using for the first time

Configure the settings for initial start­up.

Performing initial start-up

On initial start-up or after a reset to
the factory settings, you will need to
make settings.

Requirement:»The appliance has
been installed and connected.»
→Page13

1.

«Add special salt.» →Page29

2.

«Add rinse aid.» →Page31

3. «Switch on the appliance.»

→Page37

4. «Set the water softening system.»

→Page29

5. «Set the amount of rinse aid to be

dispensed.» →Page31

Tip:You can change these settings
and other «Basic settings»
→Page39 at any time.

Water softening system

Water softening system

Water softening system

Hard water leaves limescale on the
tub and tableware and parts of the
appliance may become blocked.
To ensure good dishwashing results,
you can treat the water with special
salt and the water softening system.
To avoid damage to the appliance,
water with a hardness above 9 °E
must be softened.

Overview of water hardness settings

You can find an overview of the water hardness values that can be selected
here.
You can find out how hard your water is from your local water company or by
using a water hardness tester.

Water hardness °E Hardness range mmol/l Setting value

0 — 8 Soft 0 — 1.1 H:00
9 — 10 Soft 1.2 — 1.4 H:01
11 — 12 Medium 1.5 — 1.8 H:02
13 — 15 Medium 1.9 — 2.1 H:03
16 — 20 Medium 2.2 — 2.9 H:04
21 — 26 Hard 3.0 — 3.7 H:05
27 — 38 Hard 3.8 — 5.4 H:06
39 — 62 Hard 5.5 — 8.9 H:07

Note:Set the water hardness determ­ined on your appliance.
→«Setting water softening system»,

system.
→«Switching off water softening sys-

tem», Page30

Page29

With a water hardness of 0 — 8°E
you can dispense with special salt
and switch off the water softening

28

Картинка с сайта: manualmachine.com

Water softening system en

Setting water softening sys­tem

Set the water hardness on your appli­ance.

1. Determine the water hardness and

the appropriate setting value.
→«Overview of water hardness set-

tings», Page28

2. Press ⁠.

3. Hold programme button A and

press repeatedly until the dis­play shows H:xx.

4. Release programme button A and

⁠.

a Programme button A flashes and

the display shows H:04.

5. Press programme button C re-

peatedly until the right water hard­ness has been set.

6. Press to save the setting.

Special salt

You can use special salt to soften
water.

¡ Special salt can damage the tub

due to corrosion.

▶

To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the pro­gramme starts.

1. Unscrew the lid of the dispenser

for special salt and remove.

2. On initial start-up: Fill the dispenser

right up with water.

3. Note:Only use special salt for

dishwashers.
Do not use salt tablets.
Do not use table salt.

Add the special salt to the dis­penser.

Adding special salt

If the special salt refill indicator lights
up, add special salt to the dispenser
for special salt just before the pro­gramme starts. The amount of spe­cial salt required depends on the wa­ter hardness: the higher the water
hardness, the greater the amount of
special salt required.

ATTENTION!

¡ Detergent may damage the water

softening system.

▶

Only fill the dispenser of the wa­ter softening system with special
dishwasher salt.

1

Depending on the appliance specifications

Funnel

1

Fill the dispenser right up with spe­cial salt. The water in the dis­penser is displaced and forced
out.

4. Place the lid back on the dis-

penser and turn to close.

29

Картинка с сайта: manualmachine.com

en Water softening system

Switching off water softening
system

Note

To avoid damage to the appliance, only
switch off the water softening system in
the following cases:

¡ The water hardness is max. 26°E

and you are using combined deter­gents with salt replacement sub­stances. According to manufactur­ers, combined detergents with salt
replacement substances can gen­erally only be used up to a water
hardness of 26°E without adding
special salt.

¡ The water hardness is 0 — 8°E.

You do not need to use special
salt.

1. Press ⁠.

2. Hold programme button A and

press repeatedly until the dis­play shows H:xx.

3. Release programme button A and

⁠.

a Programme button A flashes and

the display shows H:04.

4. Press programme button C re-

peatedly until the display shows
H:00.

5. Press to save the setting.

a The water softening system is

switched off and the salt refill indic­ator is deactivated.

Regeneration of the water
softening system

In order to obtain fault-free function of
the water softening system, the appli­ance performs reheating of the water
softening system at regular intervals.
Regeneration of the water softening
system takes place before the end of
the main rinse cycle in all pro­grammes. It will increase the run time
and consumption values, e.g. water
and electricity.

Overview of consumption values with regeneration the water softening
system

Here you can find an overview of the maximum additional running time and
consumption values during regeneration of the water softening system.
You can find the column applicable to your model in the quick reference guide
according to its water consumption in the Eco50° programme.

Water consump­tion in litres (de­pending on
model)

Regeneration of
the water soften­ing system after
x rinse cycles

Additional run­ning time in
minutes

Additional water
consumption in
litres

Additional power
consumption in
kWh

6.5 / 6.7 8 6 5 0.05

8.5 7 6 5 0.05

9.5 6 6 5 0.05
above 10 5 6 5 0.05

The consumption values specified
are laboratory measurements determ­ined in accordance with the currently

30

Картинка с сайта: manualmachine.com

Rinse aid system en

applicable standard and using the
Eco 50° programme and the factory
value of the water hardness is set to
16 — 20°E.

Rinse aid system

Rinse aid system

Rinse aid system

You can use the rinse aid system
and rinse aid to get tableware and
glasses rinsed perfectly without
marks.

Rinse aid

For optimum drying results, use rinse
aid.
Only use rinse aid for domestic dish­washers.

Adding rinse aid

If the rinse aid refill indicator lights
up, top up with rinse aid. Only use
rinse aid for domestic dishwashers.

1. Press the catch on the lid of the

dispenser for rinse aid and lift

⁠.

2. Add rinse aid up to the max mark.

3. If rinse aid spills out, remove it

from the tub.
Spilled rinse aid can cause ex-

cessive frothing during the wash
cycle.

4. Close the lid of the dispenser for

rinse aid.

a The lid clicks into position.

Setting the amount of rinse
aid

If there are streaks or water marks on
tableware, change the amount of
rinse aid.

1. Press ⁠.

2. Hold programme button A and

press repeatedly until the dis­play shows H:xx.

3. Release programme button A and

⁠.

a Programme button A flashes and

the display shows H:04.

4. Press programme button A re-

peatedly until the display shows
the value set at the factory r:04.

5. Press programme button C re-

peatedly until the right amount of
rinse aid has been set.

– A low setting adds less rinse aid

during the wash cycle and re­duces streaking on tableware.

31

Картинка с сайта: manualmachine.com

en Detergent

– A higher setting adds more

rinse aid during the wash cycle,
reduces water marks and im­proves the drying result.

6. Press to save the setting.

Switching rinse aid system off

If you find the rinse aid refill indicator
irritating, e.g. when using combined
detergents with a rinse aid compon­ent, you can switch the rinse aid sys­tem off.

Tip:The function of rinse aid is lim­ited with combined detergents. You
will generally get better results using
rinse aid.

1. Press ⁠.

2. Hold programme button A and

press repeatedly until the dis­play shows H:xx.

3. Release programme button A and

⁠.

a Programme button A flashes and

the display shows H:04.

4. Press programme button A re-

peatedly until the display shows
the value set at the factory r:04.

5. Press programme button C re-

peatedly until the display shows
r:00.

6. Press to save the setting.

a The rinse aid system is switched

off and the rinse aid refill indicator
is deactivated.

Detergent

Detergent

Detergent

Find out which detergents are suit­able for your appliance.

Suitable detergents

Only use detergents that are suitable
for dishwashers. Both separate and
combined detergents are suitable.
For optimum washing and drying res­ults, use separate detergent, adding
«Special salt» →Page29 and «Rinse
aid» →Page31 separately.
Modern, powerful detergents mainly
use a low-alkaline formulation with
enzymes. Enzymes break down
starch and remove protein. Oxygen­based bleaching agents are generally
used to remove coloured marks, e.g.
tea or ketchup.

Note:Follow the manufacturer’s in­structions for each detergent.

Detergent Description

Tabs Tabs are suitable for all

cleaning functions and do
not need to be measured
out.
With shorter Programmes
tabs sometimes do not dis­solve entirely and leave
residues of detergent. This
may impair the cleaning ef­fect.

Powder deter­gent

Powder detergent is re­commended for shorter
Programmes.
The dosage can be adjus­ted to the level of soiling.

32

Картинка с сайта: manualmachine.com

Detergent en

Detergent Description

Liquid detergent Liquid detergent works

faster and is recommen­ded for shorter Pro­grammes without PreR­inse.
Sometimes liquid deter­gent may leak out despite
the detergent dispenser
being closed. This is not a
fault and is non-critical if
you remember the follow­ing:
¡ Only choose a pro-

gramme without PreR­inse.

¡ Do not select timer pro-

gramming for starting
the programme.

The dosage can be adjus­ted to the level of soiling.

Tip:Suitable detergents are available
online via our website or from «Cus­tomer Services» →Page59.

Separate detergents

Separate detergents are products
that do not contain components other
than detergent, e.g. powder deter­gent or liquid detergent.
With powder and liquid detergent the
dosage can be individually adjusted
to the level of soiling of the table­ware.
For better washing and drying results
and to avoid damage to the appli­ance, please additionally use «Spe­cial salt» →Page29 and «Rinse aid»
→Page31.

Combined detergent

Besides conventional separate deter­gents, a number of products are
available with additional functions.
These products contain not only de­tergent but also rinse aid and salt re­placement substances (3in1) and,

depending on the combination (4in1,
5in1,…), additional components such
as glass protection or stainless steel
cleaner.
According to manufacturers, com­bined detergents generally only func­tion up to a water hardness of 26°E.
With a water hardness above 26°E
you will need to add special salt and
rinse aid. For the best washing and
drying results we recommend using
special salt and rinse aid from a wa­ter hardness of 17°E. If you are us­ing combined detergent, the washing
programme is adjusted automatically
to ensure the best possible washing
and drying result.

Unsuitable detergents

Do not use detergent which could
cause damage to the appliance or
present a risk to health.

Detergent Description

Hand washing-up
liquid

Detergent con­taining chlorine

Hand washing-up liquid
can cause increased froth­ing and damage the appli­ance.

Chlorine residue on table­ware may present a risk to
health.

Information on detergents

Follow the instructions on detergents
in everyday use.
¡ Detergents marked as «organic» or

«ecological» (environmentally
friendly) generally contain lower
levels of active agents or com­pletely dispense with certain sub­stances. The cleaning effect may
be restricted here.

¡ Set the rinse aid and the water

softening system to the separate
detergent or combined detergent
in use.

33

Картинка с сайта: manualmachine.com

en Detergent

¡ According to manufacturers, com-

bined detergents with salt replace­ment substances can only be used
up to a certain water hardness,
usually 26°E, without adding spe­cial salt. For the best washing and
drying results we recommend us­ing special salt from a water hard­ness of 17°E.

¡ To prevent sticking, only touch de-

tergents in a water-soluble pouch
with dry hands and only ever place
them in a dry detergent dispenser.

¡ Even if the rinse aid and special

salt refill indicators light up, wash­ing programmes will run properly
with combined detergents.

¡ The function of rinse aid is limited

with combined detergents. You will
generally get better results using
rinse aid.

¡ Use tablets with a special drying

performance.

Adding detergent

1. To open the detergent dispenser,

press the locking latch.

2. Add the detergent to the dry deter-

gent dispenser.

If you are using tablets, one is
enough. Insert the tablets in a hori­zontal position.
If you are using powder or liquid
detergent, follow the manufac­turer’s instructions and quantities
for dosage in the detergent dis­penser.
20ml–25ml detergent is suffi­cient for normal soiling. If table­ware is only lightly soiled, slightly
less than the amount of detergent
specified is usually sufficient.

34

Картинка с сайта: manualmachine.com

Tableware en

3. Close the lid of the detergent dis-

penser.

a The lid clicks into position.
a The detergent dispenser will open

automatically at the optimum time
during the programme. Powder or
liquid detergent will spread around
the washing tank and dissolve
there. Tablets will fall into the tablet
collecting tray and dissolve in the
right dosage. In order to ensure
that tablets can dissolve evenly, do
not place any other objects in the
tablet collecting tray.

Tableware

Tableware

Tableware

Only clean tableware that is suitable
for dishwashers.

Note:Decorated glassware and parts
made of aluminium or silver may
fade or discolour with dishwashing.
Delicate types of glass may turn
cloudy after a few washing cycles.

Damage to glass and table­ware

Avoid damage to glass and table­ware.

Cause Recommendation

The following table­ware is not dish­washer-safe:
¡ Items of cutlery

and tableware
made from wood

¡ Decorated glass-

ware, antique and
hand-crafted table­ware

¡ Plastic parts not

resistant to heat

¡ Tableware made

from copper or tin

¡ Tableware soiled

with ash, wax, lub­ricating grease or
paint

¡ Very small items of

tableware

Glass and tableware
was not dishwasher­safe.

The chemical com­position of the deter­gent causes damage.

Highly caustic alkaline
or highly acidic clean­ing agents, in particu­lar commercial or in­dustrial cleaning
agents, are not suit­able for dishwashers
in conjunction with
aluminium.

Only put tableware in
the dishwasher if it is
marked as dish­washer-safe by the
manufacturer.

Only put glasses and
china in the dish­washer if it is marked
as dishwasher-safe by
the manufacturer.

Use a detergent
marked as gentle on
tableware by the man­ufacturer.

If you are using highly
caustic alkaline or
highly acidic cleaning
agents, in particular
commercial or indus­trial cleaning agents,
do not put aluminium
parts in the dish­washer interior.

35

Картинка с сайта: manualmachine.com

en Tableware

Cause Recommendation

The water temperat­ure of the programme
is too high.

Select a programme
with lower temperat­ures.
After the programme
has ended, take glass­ware and cutlery out
of the appliance
without delay.

Arrange tableware

Arrange the tableware correctly to
optimise the dishwashing result and
prevent damage to both the appli­ance and tableware.

Tips

¡ Using the appliance allows you to

save energy and water compared
to washing-up by hand.

¡ See our website for examples of

how to load your appliance effi­ciently, free of charge.

¡ To save energy and water, load

the machine with the number of
place settings specified.
→«Technical specifications»,

Page60

¡ For better washing and drying res-

ults, position items with curves or
recesses at an angle so the water
can run off.

To save resources, do not pre­rinse tableware under running wa­ter.

2. Observe the following when arran-

ging tableware:
– Put heavily soiled tableware in

the bottom basket, e.g. pans.
The more powerful the spray jet,
the better the dishwashing result
will be.

– To prevent damage to table-

ware, arrange it so it is stable
and cannot tip over.

– To prevent injury, arrange cut-

lery with the points and sharp
edges downwards.

– Position containers with the

openings facing down so no wa­ter can collect in them.

– Do not block the spray arms —

make sure that they can turn
freely.

– Do not place small parts in the

tablet collecting tray and do not
block it with tableware so as not
to obstruct the lid of the deter­gent dispenser.

1. Remove large remnants of food

from your tableware.

36

Картинка с сайта: manualmachine.com

Basic operation en

Removing tableware

WARNING

Risk of injury!

Hot tableware can cause burns to the
skin. When hot, tableware is sensitive
to shock, may crack and can result in
injury.

▶

When the programme has ended,
do not empty the appliance until
the tableware has cooled down for
a while.

1. To prevent water dripping on the

tableware, unload it starting at the
bottom and working up.

2. Check the washing tank and ac-

cessories for soiling and clean if
necessary.
→«Cleaning and servicing»,

Page41

Basic operation

Basic operation

Basic operation

Opening appliance door

1. If the electric childproof lock is not

activated, press on the upper
middle section of the appliance
door.

2. If the electric childproof lock is ac-

tivated, press on the upper middle
section of the appliance door twice
with a short interval in between.

a The appliance door will open auto-

matically.

Switching on the appliance

▶

Press ⁠.
The Eco 50° programme is set by

default.
The Eco 50° programme is an es­pecially environmentally friendly
programme and ideal for normally
soiled tableware. It is the most effi-

cient programme for the combina­tion of energy/water consumption
for this type of tableware and evid­ences conformity with the EU Eco­design Directive.
If you do not perform any actions
on the appliance for 15 minutes,
the appliance will automatically
switch off.

Setting a programme

To adjust the wash cycle to the soil­ing level of the tableware, select a
suitable programme.

▶

Press the right programme button.
→«Programmes», Page18

a The programme is set and the pro-

gramme button flashes.

Setting additional functions

You can set additional functions to
complete the washing programme
selected.

Note:The additional functions which
can be used depend on the pro­gramme selected.
→«Programmes», Page18

▶

Press the button for the relevant
additional function.
→«Additional functions», Page20

a The additional function is set and

the additional function button
flashes.

Setting timer programming

You can delay the start of the pro­gramme by up to 24hours.

1. Press ⁠.

a «h:01» appears in the display.

2. Use or to set the required

start time for the programme.

3. Press ⁠.

a This activates timer programming.

37

Картинка с сайта: manualmachine.com

en Basic operation

Tip:To deactivate timer program-

ming, press or repeatedly until
«h:00» appears in the display.

Starting the programme

▶

Press .

a The programme has ended when

the display shows «0:00».

Notes

¡ If you want to add more tableware

while the appliance is running, do
not use the tablet collecting tray as
a handle for the top basket. You
might touch the partially dissolved
tablet.

¡ You can only change a pro-

gramme when running if you can­cel it.
→«Terminate programme»,

Page38

¡ The appliance switches off auto-

matically 1minute after the end of
the programme to save energy. If
you open the appliance door im­mediately after the programme has
ended, the appliance will switch off
after 4 seconds.

Terminate programme

To end a programme early or to
switch from a programme that has
already started, you will need to can­cel it first.

1. Open the appliance door.

2. Press for approx.

3seconds.

3. Close the appliance door.

a The programme is cancelled and

ends after approx. 1minute.

Switching off appliance

1. Please note the information on

«Safe use» →Page11.

2. Press .

3. To prevent damage from dripping

water, turn the water tap off tight
(not applicable to appliances with
Aqua-Stop).

Tip:If you press during the wash
cycle, the programme currently run­ning will be interrupted. When you
switch the appliance back on, the
programme continues automatically.

Interrupting programme

Note:When you open the appliance

door once the appliance has heated
up, leave the door slightly ajar for a
few minutes and then close it. This
will help prevent excess pressure
building up in the appliance and stop
the appliance door bursting open.

1. Press ⁠.

a The programme is saved and the

appliance switches off.

2. Press to resume the pro-

gramme.

38

Картинка с сайта: manualmachine.com

Basic settings

Basic settings

Basic settings

You can configure the appliance to meet your needs.

Overview of basic settings

The basic settings depend on the features of your appliance.

Basic settings en

Basic setting Display text Selection Description

Water hardness H:04

1

H:00 — H:07 Set the water softening system to

your water hardness.

→«Setting water softening system»,
Page29

Level H:00 switches the water
softening system off.

Rinse aid dispensing r:04 

1

r:00 — r:06 Set the amount of rinse aid to be dis-

pensed.

→«Setting the amount of rinse aid»,
Page31

Switch the rinse aid system off with
level r:00.

Intensive drying d:00

1

d:00 — d:01 The temperature is increased during

the final rinse, which improves the
drying result. This may increase the
run time slightly.

Note:Not suitable for delicate items
of tableware.

Switch Extra Dry on «d:01» or off
«d:00».

Hot water A:00

1

A:00 — A:01 Set cold water or hot water connec-

tion. Only set the appliance to hot
water if this can be prepared with
little energy and a suitable installa­tion is available, e.g. solar heating
system with circulation line. The wa­ter temperature should be at least
40°C and max. 60°C.
Switch hot water on «A:01» or off
«A:00».

1

Factory setting (may vary according to model)

2

Depending on the appliance specifications

39

Картинка с сайта: manualmachine.com

en Basic settings

Basic setting Display text Selection Description

TimeLight S:01

1

S:00 — S:02 Switch TimeLight on or off.

While the programme is running,
status information is projected onto
the floor below the appliance door
relating to timer programming, the
programme or the time remaining. If
the base panel is pulled forwards or
if the appliance is installed at eye
level with the cabinet front fitted
flush, the display is not visible.
Level «S:00» switches TimeLight off.

InfoLight I:01

1

I:00 — I:01 Switch InfoLight on or off.

While the programme is running, a
spot of light is projected onto the
floor below the appliance door. This
light will not be visible if the appli­ance is installed at eye level with the
cabinet front fitted flush. If the appli­ance door is not completely closed,
the spot of light will flash. The pro­gramme has ended when the spot of
light is no longer visible on the floor.
Level «I:00» switches InfoLightoff.

Tone volume b:02

1

b:00 — b:03 Adjustment of tone volume.

End of programme indicated by an
audible signal tone.
Level «b:00» switches the signal tone
off.
If the Eco drying function is activ­ated, the end of the programme is
not indicated by an audible signal
tone.

Childproof lock c:00

1

c:00 — c:01 Switch the

→«Electric childproof lock»,
Page12 on or off.

Level «c:00» switches the childproof
lock off.

Eco drying o:01

1

o:00 — o:01 Activate or deactivate automatic

door opening at the end of the Eco
programme.

Note

Eco drying is deactivated when
¡ Intensive drying is switched on.

1

Factory setting (may vary according to model)

2

Depending on the appliance specifications

40

Картинка с сайта: manualmachine.com

Cleaning and servicing en

Basic setting Display text Selection Description

¡ The Eco 50° programme has

been selected in conjunction with
one or more additional functions.

¡ The button lock has been

activated.

Level «o:00» switches Eco drying off.

1

Factory setting (may vary according to model)

2

Depending on the appliance specifications

2

Changing basic settings

1. Open the appliance door.

2. Press ⁠.

3. Hold programme button A and

press repeatedly until the dis­play shows H:xx.

4. Release programme button A and

⁠.

a Programme button A flashes and

the display shows H:04.

5. Press programme button A re-

peatedly until the display shows
the required setting.

6. Press programme button C re-

peatedly until the display shows
the right value.

You can change several settings.

7. Press to save the setting.

8. Close the appliance door.

Cleaning and servicing

Cleaning and servicing

Cleaning and servicing

To keep your appliance working effi­ciently for a long time, it is important
to clean and maintain it carefully.

Cleaning the tub

WARNING

Risk of harm to health!

Using detergents containing chlorine
may result in harm to health.

▶

Never use detergents containing
chlorine.

1. Remove any coarse soiling in the

interior with a damp cloth.

2. Add detergent to the detergent dis-

penser.

3. Select the programme with the

highest temperature.
→«Programmes», Page18

4. «Start the programme without

tableware.» →Page38

Self-cleaning interior

1

1

Depending on the appliance specifications

To remove deposits, the appliance
self-cleans the interior at regular inter­vals.
The programme sequence is auto­matically adjusted for self-cleaning,
e.g. the cleaning temperature is

41

Картинка с сайта: manualmachine.com

en Cleaning and servicing

briefly increased. Consumption val­ues, e.g. water and electricity, may
also increase.
If the interior is no longer self-cleaned
adequately and deposits occur, see
this information:
→«Cleaning the tub», Page41.

Cleaning products

Only use suitable cleaning products
to clean your appliance.
→«Safe use», Page11

Tips on appliance care

Follow the tips on appliance care to
make sure your appliance functions
properly at all times.

Action Benefit

Wipe the door seals,
the front of the dish­washer and the con­trol panel regularly us­ing a damp cloth and
washing-up liquid.

If the appliance is not
going to be used for a
while, leave the door
slightly ajar.

Machine Care

Deposits can cause your dishwasher
to malfunction, e.g. due to grease or
limescale. To avoid such faults and
reduce odours, we recommend
cleaning your appliance at regular in­tervals.
Machine Care combined with com­mercially available machine care
products is the right programme for
the care of your appliance.
Run Machine Care without tableware
if the indicator for Machine Care
lights up on the control panel or if ad-

This ensures the parts
of the appliance will
remain clean and hy­gienic.

This will prevent un­pleasant odours.

1

vised to do so by the display. Once
you have run the Machine Care pro­gramme, the indicator goes out. If
your appliance does not have a re­minder function, follow the directions
for use on the machine care
products.

Performing Machine Care

Run the Machine Care programme if
the indicator for Machine Care lights
up on the control panel or if advised
to do so by the display.

Notes

¡ Run the Machine Care programme

without any tableware in the dish­washer.

¡ Only use suitable machine care

products specially designed for
dishwashers and not dishwasher
detergent. Observe the manufac­turer’s instructions.

¡ Make sure that there are no alu-

minium parts in the interior of the
appliance.

¡ If you have not run Machine Care

after 3 washing cycles, the indic­ator for Machine Care will go out
automatically.

¡ Follow the safety instructions and

the directions for use on the pack­agings of the machine care
products.

1. Remove any coarse soiling in the

interior with a damp cloth.

2. Clean filters.

3. Add the machine care product to

the appliance.

4. Press ⁠.

5. Press ⁠.

a The Machine Care programme is

run.

a As soon as machine care has fin-

ished, the indicator for Machine
Care goes out.

1

Depending on the appliance specifications

42

Картинка с сайта: manualmachine.com

Cleaning and servicing en

Filter system

The filter system removes coarse
soiling from the dishwashing cycle.

Micro filter

Fine filter

Coarse filter

Cleaning filters

Soiling in the dishwashing water may
block the filters.

1. After each wash check the filters

for residue.

2. Turn the coarse filter anticlockwise

and remove the filter system ⁠.

‒ Check that no foreign objects

fall into the sump.

3. Pull down the micro filter to re-

move.

4. Press the locking catches to-

gether and lift the coarse filter out

⁠.

5. Clean the filter elements under run-

ning water.
Carefully clean the rim of dirt

between the coarse and the fine fil­ter.

6. Re-assemble the filter system.

Make sure that the locking catches
on the coarse filter click into posi­tion.

7. Insert the filter system into the ap-

pliance and turn the coarse filter
clockwise.

Make sure that the arrow markings
match up.

43

Картинка с сайта: manualmachine.com

en Cleaning and servicing

Cleaning spray arms

Limescale and soiling in the dish­washing water may block the nozzles
and bearings on the spray arms.
Clean the spray arms regularly.

1. Unscrew the upper spray arms

and pull down to remove .

2. Pull up the lower spray arm to re-

move.

3. Check the outlet nozzles on the

spray arms for blockages under
running water and remove any for­eign bodies.

4. Insert the lower spray arm.

a The spray arm clicks into position.

5. Insert the upper spray arms and

screw firmly in place.

44

Картинка с сайта: manualmachine.com

Troubleshooting en

Troubleshooting

Troubleshooting

Troubleshooting

You can rectify minor faults on your appliance yourself. Read the troubleshoot­ing information before contacting Customer Service. This will avoid unneces­sary costs.

WARNING

Risk of electric shock!

Improper repairs are dangerous.

▶

Repairs to the appliance should only be carried out by trained specialist
staff.

▶

Only use genuine spare parts when repairing the appliance.

▶

If the power cord of this appliance is damaged, it must be replaced with a
special connection cable, which is available from the manufacturer or his
Customer Service.

Appliance safety

Fault Cause Troubleshooting

Appliance door will not open
or cannot be opened easily.

Appliance door does not
open at the end of the Eco
50° programme.

Childproof lock is activated.

Eco drying is deactivated.

Childproof lock is activated.

Eco 50° programme not se-

▶

Activate Eco drying.

▶

Deactivate the childproof lock.

▶

Select the Eco 50° programme.

lected.
Additional function selected.▶Deselect the additional function.

Extra Dry/Intensive drying is
activated.

▶

Deactivate Extra Dry/Intensive dry­ing.

→«Overview of basic settings»,
Page39

Door is not correctly adjus­ted.

▶

Adjust the appliance door as de­scribed in the installation instruc­tions.

The door gap must be at least
70mm — 100mm.

Appliance door and door
seal are soiled.

▶

Clean the appliance door and door
seal with a damp cloth and a little
washing-up liquid.

Wrong screws used to ad­just the door gap.

▶

Use size 4X30 screws to adjust the
door gap.

The screws are included in the
scope of supply.

45

Картинка с сайта: manualmachine.com

en Troubleshooting

Fault Cause Troubleshooting

Appliance door does not
open at the end of the Eco
50° programme.

Appliance door automatic­ally opens too wide at the
end of the Eco 50° pro­gramme.

The safety device will switch
Eco drying off.

Door is not correctly adjus­ted.

If the screws used here are too
long, this may deactivate Eco dry­ing.

▶

Call «Customer Service.»

→Page59

▶

Adjust the appliance door as de­scribed in the installation instruc­tions.

The door gap must be at least
70mm — 100mm.

Wrong screws used to ad­just the door gap.

▶

Use size 4X30 screws to adjust the
door gap.

The screws are included in the
scope of supply.
If the screws used here are too
long, this may deactivate Eco dry­ing.

Appliance door does not
open.

Door is not correctly adjus­ted.

▶

Adjust the appliance door as de­scribed in the installation instruc­tions.

Appliance has no power.

▶

Check the mains plug and fuses.

1. Position the emergency release

supplied on the top right and left of
the cabinet panel.

46

Appliance door and door
seal are soiled.

Automatic door opening is
not in home position.

2. Open the appliance door by pulling

lightly.

▶

Clean the appliance door and door
seal with a damp cloth and a little
washing-up liquid.

▶

Wait one second after closing the
appliance door.

Картинка с сайта: manualmachine.com

Fault Cause Troubleshooting

Appliance door opens too
wide when activated.

Door is not correctly adjus­ted.

▶

Adjust the appliance door as de­scribed in the installation instruc­tions.

Error code / Fault display / Signal

Fault Cause Troubleshooting

E:12 lights up. Heating element is furred

up.

E:14 lights up. Water protection system is

activated.

E:15 lights up. Water protection system is

activated.

E:16 lights up. Water is continuously run-

ning into the appliance.

E:18 or indicator for water

Supply hose is kinked.

supply lights up.

Water tap is turned off.

Water tap is jammed or
furred up.

Filter in the water supply is
blocked.

1. Descale the appliance.

2. Operate the appliance with the Wa-

ter softening system.

1. Turn off the water tap.

2. Call «Customer Service»

→Page59.

1. Turn off the water tap.

2. Call «Customer Service»

→Page59.

1. Turn off the water tap.

2. Call «Customer Service»

→Page59.

▶

Install the supply hose without
kinks.

▶

Turn on the water tap.

▶

Turn on the water tap.
The flow rate must be at least 10 l/

min when the water supply is open.

1. Switch off the appliance.

2. Pull out the mains plug.

3. Turn off the water tap.

4. Unscrew the water connection.

5. Remove the filter from the supply

hose

Troubleshooting en

6. Clean the filter.

47

Картинка с сайта: manualmachine.com

en Troubleshooting

Fault Cause Troubleshooting

E:18 or indicator for water
supply lights up.

7. Re-insert the filter in the supply

hose.

8. Screw the water connection back

on.

9. Check the water connection for

leaks.

10. Restore the power supply.

11. Switch the appliance on.

E:22 lights up.

1

Filters are soiled or blocked.▶Clean the filters.

→«Cleaning filters», Page43

E:24 lights up. Wastewater hose is blocked

or kinked.

Siphon connection is still
sealed.

Cover of the wastewater
pump is loose.

1. Reposition the wastewater hose

without kinks.

2. Remove residues.

▶

Check the connection to the siphon
and open if necessary.

▶

Secure the cover of the «Wastewa­ter pump » →Page58 so it clicks
into position.

E:25 lights up. Wastewater pump is

blocked.

▶

Clean the wastewater pump.

→«Clean wastewater pump»,
Page58

Cover of the wastewater
pump is loose

▶

Secure the cover of the «Wastewa­ter pump » →Page58 so it clicks
into position.

E:27 lights up. Mains voltage is too low. This is not a fault on the appliance.

1. Contact an electrician.

2. Have the mains voltage and elec-

trical installation checked by an
electrician.

1

Depending on the appliance specifications

48

Картинка с сайта: manualmachine.com

Fault Cause Troubleshooting

Another error code appears
on the display.

E:01 to E:30

A technical fault is present. 1. Press .

2. Unplug the appliance or switch off

the fuse.

3. Wait at least 2minutes.

4. Insert the mains plug of the appli-

ance in a socket or switch on the
fuse.

5. Switch the appliance on.

6. If the problem occurs again:

‒ Press ⁠.
‒ Turn off the water tap.
‒ Pull out the mains plug.
‒ Contact «Customer Service»

→Page59 and give the er-
ror code.

Washing results

Fault Cause Troubleshooting

Tableware is not dry. No rinse aid used or dosage

set too low.

Selected programme has no
drying phase

Water collects in recesses of
the tableware or cutlery.

1. Add «Rinse aid» →Page31.

2. Set the amount of rinse aid to be

dispensed.

▶

Select a programme with drying.

▶

Position tableware at an angle
where possible.

Troubleshooting en

The combined detergent
used has a poor drying per­formance.

Extra Dry not activated to im­prove drying performance.

1. Use rinse aid to improve drying per-

formance.

2. Use a different combined detergent

with a better drying performance.

▶

Activate Extra Dry.

49

Картинка с сайта: manualmachine.com

en Troubleshooting

Fault Cause Troubleshooting

Tableware is not dry. Tableware removed too

early or drying process not
yet ended.

Rinse aid used has a limited
drying performance.

1. Wait until the programme ends.

2. Only remove tableware 30minutes

after the programme has ended.

▶

Use a name-brand rinse aid.
Eco products may have limited ef-

fectiveness.

Appliance door does not
open automatically at the
end of the Eco 50° pro­gramme

▶

Adjust the appliance door as de­scribed in the installation instruc­tions.

The door gap must be at least
70mm — 100mm.

Plastic tableware is not dry. Not a fault. As plastic does

▶

No remedial action possible.
not store heat so well, it also
does not dry as well.

Cutlery is not dry. Cutlery not arranged prop-

erly in the cutlery basket or
cutlery drawer.

1. Arrange the cutlery properly.

→«Arrange tableware», Page36

2. Arrange cutlery individually where

possible.

3. Avoid points of contact.

Appliance interior still wet
after wash cycle.

Not a fault. The condensa­tion drying principle causes

No action required.

water droplets in the tub –
they are indeed desirable
here. The moisture in the air
condenses on the inside
walls, runs off and is
pumped out.

Remnants of food on table­ware.

Tableware was placed too
close together.

1. Arrange tableware with sufficient

space in between.

The spray jets must reach the sur-

faces of the tableware.

2. Avoid points of contact.

Basket is overfilled. 1. Arrange tableware with sufficient

space in between.

The spray jets must reach the sur-

faces of the tableware.

2. Avoid points of contact.

Spray arm rotation is
blocked.

Spray arm nozzles are

▶

Arrange tableware so that it does

not obstruct spray arm rotation.

▶

Clean the «Spray arms» →Page44.
blocked.

50

Картинка с сайта: manualmachine.com

Fault Cause Troubleshooting

Remnants of food on table­ware.

Filters are soiled.

Filters are inserted incor­rectly and/or not engaged.

Washing programme selec­ted too weak.

Tableware has been pre­cleaned too intensely. The

▶

Clean the filters.

→«Cleaning filters», Page43

1. Insert the filters properly.

→«Filter system», Page43

2. Engage the filters.

▶

Select a more intensive washing

programme.

▶

Adjust the sensitivity of the sensors.

▶

Only remove large remnants of food

and do not prerinse tableware.
sensors chose a weaker pro­gramme. Stubborn soiling
cannot be entirely removed.

Tall narrow receptacles in
corner areas are not rinsed
adequately.

Top baskets on right and left
are not set to same height.

▶

Do not position tall narrow recept-

acles at too great an angle or in

corner areas.

▶

Set the top baskets on the left and

right to the same level.

→«Top basket», Page22

Detergent residue in the ap­pliance

Lid of the detergent dis­penser is blocked by items
of tableware parts and will
not open.

1. Arrange tableware in the top basket

tableware so the tab collecting tray

is not obstructed by tableware.

→«Arrange tableware», Page36

Items of tableware are blocking the

dispenser lid.

2. Do not place tableware or fra-

grance dispensers in the tablet col-

lecting tray.

The lid of the detergent dis­penser is blocked by the tab

▶

Position the tab in the detergent dis-

penser crosswise, not vertically.
and will not open.

Tabs are used in the quick
or short programme. Dissolv­ing time of the tab is not at-

▶

Select a more intensive Programme

or use «Powder detergent»

→Page32.
tained.

Washing effect and dissolv­ing performance are re-

▶

Change your «detergent»

→Page32.
duced after a prolonged
storage time or detergent is
very lumpy.

Troubleshooting en

51

Картинка с сайта: manualmachine.com

en Troubleshooting

Fault Cause Troubleshooting

Water marks on plastic
parts.

Due to laws of physics
droplet formation on plastic
surfaces is unavoidable.
After drying water marks are
visible.

▶

Select a more intensive pro-

gramme.

▶

Position tableware at an angle.

→«Arrange tableware», Page36

▶

Use rinse aid.

→«Rinse aid», Page31

▶

Set the water softening system

higher.

Wipeable or water-soluble
coatings are present inside
the appliance or on the door.

Detergent substances are
deposited there. These coat­ings cannot generally be re­moved with chemicals.

White coating is deposited in
the appliance interior.

▶

Change your «detergent»

→Page32.

▶

Clean the appliance mechanically.

1. Set the water softening system cor-

rectly.

In most cases you will need to in-

crease the setting.

2. Change your detergent if required.

▶

Screw the special salt dispenser

tight.

▶

Change your «detergent»

→Page32.

▶

Clean the appliance mechanically.

▶

Set the «Water softening system»

→Page28 to the water hardness

or add special salt.

Stubborn white coatings are
present on tableware, inside
the appliance or the door.

Special salt dispenser is not
screwed tight.

Detergent substances are
deposited there. These coat­ings cannot generally be re­moved with chemicals.

The hardness range is set in­correctly or the water hard­ness is greater than 62°E
(8,9mmol/l).

3in1/organic/eco detergent
is not effective enough.

▶

Set the «Water softening system»

→Page28 to the water hardness

and use separate detergents (pro-

prietary detergent, special salt,

rinse aid).

Too little detergent is being
used.

▶

Increase the amount of detergent

used or change «Detergent «

→Page32.

▶

Select a more intensive washing

programme.

▶

Adjust the sensitivity of the sensors.

▶

Select a programme with a higher

washing temperature.

Tea residue or lipstick marks
on tableware.

Washing programme selec­ted too weak.

Washing temperature is too
low.

52

Картинка с сайта: manualmachine.com

Fault Cause Troubleshooting

Tea residue or lipstick marks
on tableware.

Too little detergent is being
used or is unsuitable.

▶

Use a suitable «Detergent «

→Page32 and follow the manufac-

turer’s instructions for the amount

to be used.

Tableware has been pre­cleaned too intensely. The

▶

Only remove large remnants of food

and do not prerinse tableware.
sensors chose a weaker pro­gramme. Stubborn soiling
cannot be entirely removed.

Coloured coatings (blue, yel­low, brown) that are difficult
or impossible to remove are
present inside the appliance
or on stainless steel table­ware.

The formation of films is due
to substances contained in
vegetables (cabbage, celery,
potatoes, noodles, etc.) or
tap water (manganese).

▶

Clean the appliance.

You can remove deposits with

«Mechanical cleaning» →Page41

or a machine cleaning product. It

may not always be possible to com-

pletely remove deposits but they

are harmless to health.

The formation of films is due
to metal components on sil­ver or aluminium tableware.

▶

Clean the appliance.

You can remove deposits with

«Mechanical cleaning» →Page41

or a machine cleaning product. It

may not always be possible to com-

pletely remove deposits but they

are harmless to health.

Coloured deposits (yellow,
orange, brown) that are easy
to remove are present inside
the appliance (mainly at the
bottom).

The formation of films is due
to ingredients of food rem­nants and tap water (limes­cale) «soaplike».

1. Check the setting of the water

softening system.

→«Setting water softening system»,

Page29

2. Add special salt.

→«Adding special salt», Page29

3. If you are using combined deter-

gents (tabs), activate the water

softening system.

Follow the information about deter-

gents.

→«Information on detergents»,

Page33

Plastic parts inside the appli­ance are discoloured.

Plastic parts inside the appli­ance may become discol­oured during the life of the

▶

Discolouration can come about and

will not impair functioning of the ap-

pliance.
dishwasher.

Plastic parts are discol­oured.

Washing temperature is too
low.

▶

Select a programme with a higher

washing temperature.

Troubleshooting en

53

Картинка с сайта: manualmachine.com

en Troubleshooting

Fault Cause Troubleshooting

Plastic parts are discol­oured.

Tableware has been pre­cleaned too intensely. The

▶

Only remove large remnants of food

and do not prerinse tableware.
sensors chose a weaker pro­gramme. Stubborn soiling
cannot be entirely removed.

Removable streaks are
present on glasses, glass­ware with a metallic appear­ance and cutlery.

Amount of rinse aid to be
dispensed is set too high.

No rinse aid has been ad­ded.

Detergent residue is present
in the final rinse. Lid of the
detergent dispenser is
blocked by tableware items
and will not open fully.

▶

Set the rinse aid system to a lower

setting.

▶

→«Adding rinse aid», Page31

1. Arrange tableware in the top basket

tableware so the tab collecting tray

is not obstructed by tableware.

→«Arrange tableware», Page36

Items of tableware are blocking the

dispenser lid.

2. Do not place tableware or fra-

grance dispensers in the tablet col-

lecting tray.

Tableware has been pre­cleaned too intensely. The
sensors chose a weaker pro­gramme. Stubborn soiling

▶

Only remove large remnants of food

and do not prerinse tableware.

▶

Adjust the sensitivity of the sensors.

cannot be entirely removed.

Irreversible clouding of
glassware.

Glasses are not dishwasher­proof, only suitable for dish­washers.

▶

Use dishwasher-proof glasses.

▶

Avoid a lengthy steam phase

(standing time after wash cycle

ends).

▶

Use a programme with a lower tem-

perature.

▶

Set the softening system to the wa-

ter hardness.

▶

Use detergent with a glass protec-

tion component.

Rust spots on cutlery. Cutlery is not sufficiently

▶

Use rust-resistant tableware.
rust-resistant. Knife blades
are often more severely af­fected.

Cutlery may also rust if

▶

Do not wash rusting items.
washed together with rust­ing items.

54

Картинка с сайта: manualmachine.com

Fault Cause Troubleshooting

Rust spots on cutlery. Salt content in washing wa-

ter is too high.

1. Remove any spilled special salt

from the tub.

2. Screw the cap of the special salt

dispenser on tight.

Detergent residue is present
in the detergent dispenser
or the tablet collecting tray.

Spray arms were blocked by
tableware so detergent was
not rinsed out.

Detergent dispenser was
damp when detergent was

▶

Check that the spray arms are not

blocked and can rotate freely.

▶

Only add detergent to a detergent

dispenser when dry.
added.

Excessive formation of foam
occurs.

Hand washing-up liquid is
present in dispenser for
rinse aid.

Rinse aid has been spilled.

Detergent or appliance care

▶

Immediately add rinse aid to the

dispenser.

→«Adding rinse aid», Page31

▶

Remove the rinse aid with a cloth.

▶

Change the brand of detergent.
product used causes excess­ive foaming.

Information on display panel

Fault Cause Troubleshooting

Special salt refill indicator
lights up.

Insufficient special salt.

Sensor does not detect spe­cial salt tablets.

Refill indicator for special
salt does not light up.

Refill indicator for rinse aid

Water softening system is
switched off.

Insufficient rinse aid. 1. Add «Rinse aid» →Page31.

lights up.

Refill indicator for rinse aid
does not light up.

Rinse aid system is switched
off.

Display flashes. Appliance door is not closed

properly.

▶

Add «Special salt» →Page29.

▶

Do not use special salt tablets.

▶

«Setting water softening system»

→Page29

2. Set the amount of rinse aid to be

dispensed.

▶

→«Setting the amount of rinse aid»,

Page31

▶

Close the appliance door.

‒ Arrange the tableware so

that no parts project beyond
the basket and prevent the
appliance door from closing
properly.

Troubleshooting en

55

Картинка с сайта: manualmachine.com

en Troubleshooting

Fault Cause Troubleshooting

Machine Care indicator
lights up.

Machine care is recommen­ded.

▶

Run the Machine Care programme

without tableware.

‒ Use a special machine care

product.
The indicator will go out automatic­ally after 3 wash cycles whether
Machine Care is carried out or not.

Malfunctions

Fault Cause Troubleshooting

Water is left in the appliance
at the end of the pro­gramme.

Appliance cannot be
switched on or operated.

Appliance does not start. The mains fuse has tripped.

Programme starts automat­ically.

Appliance stops during the
programme or cuts out.

Filter system or area under
the filters is blocked.

1. Clean the «Filters» →Page43.

2. Clean the «Wastewater pump»

→Page58.

Programme has not yet
ended.

▶

Wait until the programme ends or
cancel the programme with reset.

▶

→«Terminate programme»,
Page38

Appliance functions have
failed.

1. Pull out the mains plug or switch off

the fuse.

2. Wait at least 2minutes.

3. Connect the appliance to the power

supply.

4. Switch the appliance on.

▶

Check the relevant fuse.

Mains cable is not inserted. 1. Check whether the socket works.

2. Check whether the mains cable is

properly inserted in the socket and
on the rear of the appliance.

Appliance door is not closed

▶

Close the appliance door.

properly.
You did not wait until pro-

gramme ended.

Appliance door is not closed

▶

→«Terminate programme»,
Page38

▶

Close the appliance door.

properly.
Power and/or water supply

has been interrupted.

1. Check the power supply.

2. Check the water supply.

56

Картинка с сайта: manualmachine.com

Fault Cause Troubleshooting

Appliance stops during the
programme or cuts out.

Top basket is pressing
against inner door and pre­venting appliance door from
being closed securely.

▶

Check whether the rear panel of the
appliance is being pressed in by a
socket or hose holder that has not
been removed.

▶

Arrange the tableware so that no
parts project beyond the basket
and prevent the appliance door
from closing properly.

Mechanical damage

Fault Cause Troubleshooting

Appliance door cannot be
closed.

Lid on the detergent dis­penser cannot be closed.

Door lock has been activ­ated.

Door cannot be closed due
to installation method.

Automatic door opening is
not in home position.

Detergent dispenser or lid
are blocked by sticky deter­gent residue.

▶

Close the appliance door with
greater force.

▶

Check whether the appliance has
been installed properly.

When closed, the appliance door,
its decor or attached parts should
not knock against adjacent cabin­ets or the worktop.

▶

Wait for a second after opening the
appliance door.

▶

Remove detergent residue.

Troubleshooting en

Noise

Fault Cause Troubleshooting

Filling valves making knock­ing noises.

Caused by the domestic in­stallation. No appliance fault
present. Does not affect
functioning of the appliance.

Knocking or rattling noise. Spray arm is striking table-

ware.

With a small load the water
jets directly strike against
the tub.

Light items of tableware
move about during the wash
cycle.

▶

Can only be remedied in the do­mestic installation.

▶

Arrange tableware so that the spray
arms do not strike tableware.

▶

Distribute the tableware evenly.

▶

Load the appliance with more table­ware.

▶

Position light items of tableware se­curely.

57

Картинка с сайта: manualmachine.com

en Transportation, storage and disposal

Clean wastewater pump

Large remnants of food or foreign
bodies can block the wastewater
pump. As soon as the washing water
no longer drains properly, the
wastewater pump must be cleaned.

WARNING

Risk of injury!

Sharp and pointed objects or frag­ments of glass may block the waste
water pump and cause injury.

▶

Remove any foreign bodies care­fully.

1. Disconnect the appliance from the

power supply.

2. Remove the top and bottom bas-

ket.

3. Remove the filter system.

4. Scoop out any water.

Use a sponge if necessary.

5. Prise off the pump cover using a

spoon and grip it by the
crosspiece.

8. Insert the pump cover and press

down ⁠.

a The pump cover clicks into posi-

tion.

9. Install the filter system.

10.Insert the top and bottom basket.

Transportation, storage and disposal

Transportation, storage
and disposal

Transportation, storage and disposal

You can find out here how to prepare
your appliance for transportation and
storage. You will also find out how to
dispose of old appliances.

6. Lift the pump cover inwards at an

angle and remove.

7. Remove any remnants of food and

foreign bodies in the area of the
impeller.

58

Removing the appliance

1. Disconnect the appliance from the

power supply.

2. Turn off the water tap.

3. Detach the drainage connection.

4. Detach the drinking water connec-

tion.

5. Loosen any screws fastening the

appliance to cabinet parts.

6. Remove the base panel if fitted.

7. Pull the appliance out carefully,

along with the hose behind it.

Картинка с сайта: manualmachine.com

Customer Service en

Protect appliance from frost

If there is a risk of frost where the ap­pliance will be standing, e.g. in a holi­day home, empty the appliance com­pletely.

▶

«Empty the appliance.»
→Page59

Transporting the appliance

To avoid damage to the appliance,
empty it before transporting.

Note:Always transport the dish­washer upright to prevent residual
water getting into the machine’s con­trols and damaging the appliance.

1. Remove tableware from the appli-

ance.

2. Secure loose parts.

3. Turn on the water tap.

4.

«Switch on appliance.» →Page37

5. Select the programme with the

highest temperature.
→«Programmes», Page18

6.

«Start the programme.» →Page38

7. To drain the appliance, terminate

the programme after approx.
4minutes.
→«Terminate programme»,

Page38

8. «Switch off the appliance.»

→Page38

9. Turn off the water tap.

10.To empty the residual water out of

the appliance, detach the supply
hose and let the water drain out.

Disposing of old appliance

Valuable raw materials can be re­claimed by recycling.

WARNING

Risk of harm to health!

Children can lock themselves in the
appliance, thereby putting their lives
at risk.

▶

With redundant appliances, unplug
the power cord. Then cut through
the cord and damage the lock on
the appliance door beyond repair
so that the appliance door will no
longer close.

1. Unplug the appliance from the

mains.

2. Cut through the power cord.

3. Dispose of the appliance in an en-

vironmentally friendly manner.

This appliance is labelled in ac­cordance with European Direct­ive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment — WEEE).
The guideline determines the
framework for the return and re­cycling of used appliances as
applicable throughout the EU.

Customer Service

Customer Service

Customer Service

If you have any queries, are unable to
rectify faults on the appliance your­self or if your appliance needs to be
repaired, contact Customer Service.
You can solve many problems your­self by consulting the information on
troubleshooting in these instructions
or on our website. If this is not the
case, contact our after-sales service.

59

Картинка с сайта: manualmachine.com

en Technical specifications

With any warranty claims, we will
make sure that your appliance is re­paired by trained after-sales techni­cians using genuine spare parts, in­cluding after the manufacturer’s war­ranty has expired.
Function-relevant genuine spare parts
according to the corresponding Eco­design Order can be obtained from
Customer Service for a period of at
least 10 years from the date on
which your appliance was placed on
the market within the European Eco­nomic Area.

Note:Under the terms of the manu­facturer’s warranty the use of Cus­tomer Service is free of charge.

Detailed information on the warranty
period and terms of warranty in your
country is available from our after­sales service, your retailer or on our
website.
If you contact Customer Service, you
will require the product number (E­Nr.) and the production number (FD)
of your appliance.
The contact details for Customer Ser­vice can be found in the enclosed
Customer Service directory or on our
website.

Product number (E-Nr.) and
production number (FD)

You can find the product number (E­Nr.) and the production number (FD)
on the appliance’s rating plate.
The rating plate is located inside the
appliance door.
Make a note of your appliance’s de­tails and the Customer Service tele­phone number to find them again
quickly.

AQUA-STOP guarantee

1

In addition to warranty claims against
the seller under the purchase agree­ment and in addition to our manufac­turer’s warranty, we will provide a re­placement under the following condi­tions.
¡ If our Aqua-Stop system is defect-

ive and causes water damage, we
will make good the damage for
private users. To ensure protection
from water damage, the appliance
must be connected to the power
supply.

¡ The liability guarantee is valid for

the service life of the appliance.

¡ A claim can only be made under

the guarantee if the appliance has
been correctly installed and con­nected with Aqua-Stop according
to our instructions; this also in­cludes correctly fitting the Aqua­Stop extension (genuine access­ory). Our guarantee does not cover
defective supply lines or fittings up
to the Aqua-Stop connection on
the tap.

¡ If your appliance is fitted with

Aqua-Stop, you can leave your ap­pliance unattended during opera­tion and the tap turned on after­wards. The tap only needs to be
turned off if you are away from
home for a long period, e.g. on
holiday for several weeks.

Technical specifications

Technical specifications

Technical specifications

Facts and figures for your appliance
can be found here.

Weight Max.: 45kg
Voltage 220 — 240V, 50Hz or

60Hz

1

Depending on the appliance specifications

60

Картинка с сайта: manualmachine.com

Technical specifications en

Power rating 2000 — 2400W
Fuse 10 — 16A
Power consumption Off mode/standby

mode: 0.20W
Left-on mode: 0.20W
Networked standby: ­W
Time in left-on mode:
0min
Time after which ap­pliance is switched to
networked standby
mode: -min
Complies with the
latest regulations (EU)
for energy labels and
ecodesign at the time
of placing on the mar­ket.
Additional functions
and settings may in­crease power con­sumption and times.

Water pressure ¡ Min. 0.05MPa

(0.5bar)

¡ Max. 1MPa

(10bar)
Inlet rate Min. 10l/min
Water temperature Cold water.

Hot water max.: 60°C

Capacity 9-10place settings

This product contains light sources
from energy efficiency class G. These
light sources are available as a spare
part and should only be replaced by
trained specialist staff.

1

More information about your model
can be found online at https://en­ergylabel.bsh-group.com2. This web
address is linked to the official EU
EPREL product database. At the time
of printing its web address had not

yet been published. Please then fol­low the instructions on searching for
models. The model identifier is made
up of the characters before the slash
in the product number (E-Nr.) on the
rating plate. Alternatively you can
also find the model identifier in the
first line of the EU energy label.

1

Depending on the appliance specifications

2

Only applies to countries in the European Economic Area

61

Картинка с сайта: manualmachine.com

BSH Hausgeräte GmbH

Carl-Wery-Straße 34
81739 München
GERMANY
www.siemens-home.bsh-group.com

Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG

*9001496633*

9001496633 (001005) 440 MV
en
